- Page 1 R20AD 10-bit Universal Decoder R-series Card Module Published: 6/30/10 Installation and Operation Guide B e c a u s e m a t t e r s .
-
Page 2: Contacting Support
Video parts or supplies, or d) to service a product that has been modified or integrated with other products when the effect of such a modification or integration increases the time or difficulty of servicing the product. - Page 3 NTSC/PAL configuration is automatic. Video format, AGC, H/V blanking, and pedestal are all user configurable. The R20AD is a 10.3” X 3.1” card, designed to plug into The AJA Video FR1-1 RU frame and the AJA Video FR2-2 RU frame.
-
Page 4: Block Diagram
R20AD Rear Panel FR1 and FR2 BNC Connector Assignments, R20AD Card Module When the R20AD module is installed in an AJA FR1 or FR2 frame, a corresponding group of 9 BNCs on the rear panel then provide I/O for the module. The illustration above shows the connector assignments for both the FR1 and FR2 when used with the R20AD. -
Page 5: User Controls
AJA R20AD 10-bit Universal Decoder User Manual User Controls The user interface for the R20AD consists of a 16-position hex rotary switch, a momentary action up/down toggle switch, and 6 LEDs that indicate status. The rotary switch selects a function or setting to be controlled by the toggle switch. The BANK LED (LED 1) shows which of two banks of functions are to be accessed. - Page 6 Bank 0 Functions FUNCTION DESCRIPTION DETAILS BANK SEL Toggle UP/LEFT to select BANK 1 Toggle DOWN/RIGHT to select BANK 0 (Default) INPUT MODE Toggle to cycle through these selections: Auto Select (Default). Currently, AUTO SELECT is the only selection. VERTICAL BLANK UP/LEFT = Blank Vertical Interval DOWN/RIGHT = Pass Vertical Interval (Default) Currently, Pass Vertical Interval (narrow blanking) is the...
-
Page 7: Installation
AJA R20AD 10-bit Universal Decoder User Manual Bank 1 Functions—Frame Sync Option Only FUNCTION DESCRIPTION DETAILS BANK SEL Toggle UP/LEFT to select BANK 1 Toggle DOWN/RIGHT to select BANK 0 (Default) SET DEFAULT DELAY Toggle UP/LEFT or DOWN/RIGHT = Restores FSG to... - Page 8 Warning! FR2 Dual Power Cord Notice—please read this. To reduce the risk of electrical shock, disconnect both power cords before servicing equipment. Caution! The FR1/FR2 front fan door is heavy and is not hinged. Remove with Caution. Instructions for removing the frame front door for module installation is discussed in the FR1/FR2 User Manual.
-
Page 9: Genlock Mode
AJA R20AD 10-bit Universal Decoder User Manual Front of Card Reference Select: FRAME = Selects Aux Reference Strapping BNC on Frame LOOP FRAME Field (J3) LOOP = Selects Reference Loop BNC Termination: Jumpers shown with Reference Select set to “LOOP”... -
Page 10: Specifications
NTSC or PAL Analog Color Black Number of Outputs: 4 BNC A/D Converters: 10-bits, 2x oversampling Size: Fits AJA R-Series Frames. Compatible with Leitch 6800 Series Frames. Frequency Response: Y +/- .15dB to 5.5MHz C +/- .15dB to 2.5MHz Power Consumption:... - Page 11 AJA R20AD 10-bit Universal Decoder User Manual Appendix A: Safety & Compliance Federal Communications Commission (FCC) Compliance Notices Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15, Subpart B of the FCC Rules. These limits are designed to provide reasonable Interference protection against harmful interference in a commercial installation.
-
Page 12: Declaration Of Conformity
Declaration of Marking by this symbol indicates compliance with the Essential Requirements of the EMC Directive of the European Union 2004/108/EC. Conformity This equipment meets the following conformance standards: Safety: CB- IEC 60065:2001 + A1:2005 NRTL - UL 60065:2003 R11.06, CSA C22.2 NO. 60065:2003 + A1:06 GS - EN 60065:2002 + A1 Additional licenses issued for specific countries available on request. -
Page 13: Taiwan Compliance Statement
AJA R20AD 10-bit Universal Decoder User Manual Taiwan Compliance Statement This is a Class A product based on the standard of the Bureau of Standards, Metrology and Inspection (BSMI) CNS 13438, Class A. Japanese Compliance Statement 1. Class A ITE この装置は、... - Page 14 Warning! Do not use this device near water and clean only with a dry cloth. Avertissement! N'utilisez pas cet appareil près de l'eau et nettoyez-le seulement avec un tissu sec.. Warnung! Das Gerät nicht in der Nähe von Wasser verwenden und nur mit einem trockenen Tuch säubern.
- Page 15 AJA R20AD 10-bit Universal Decoder User Manual des objets sont tombés dans l'appareil, que l'appareil a été exposé à la pluie ou à l'humidité, ne fonctionne pas normalement ou est tombé. Warnung! Das Gerät sollte nur von qualifizierten Fachkräften gewartet werden. Eine Wartung ist fällig, wenn das Gerät in irgendeiner Weise beschädigt wurde, wie bei beschädigtem...
- Page 16 Warning! Ensure Mains Power is disconnected before installing the FR1 or FR2 frame R- series modules into the frame, or installing and removing options. If a Mains switch is not provided, the power cord(s) of this equipment provide the means of disconnection.
- Page 17 AJA R20AD 10-bit Universal Decoder User Manual Caution! The FR1/FR2 front fan door is heavy and is not hinged. Remove with Caution. Attention ! La porte frontale du ventilateur de FR1/FR2 est lourde et ne repose pas sur des charnières. Retirer avec précaution.
