DC Connector
DC Connector
WARNING!
DO NOT APPLY AC VOLTAGE TO THIS UNIT THROUGH THE 6 PIN CONNECTOR
ON THE REAR OF THE UNIT!
Failure to follow these directions will cause injury or death to personnel, cause
irreparable damage to the instrument and void all warranties.
WARNING!
DO NOT REVERSE THE POLARITY OF THE SUPPLY VOLTAGE!
Reversing the polarity of the power supply will cause damage to the unit and void
all warranties.
WARNING!
The chassis of the instrument is internally connected to DC ground.
The +24 VDC connector is wired as follows:
Pin 1 NC
Pin 2 NC
Pin 3 NC
Pin 4 +24 VDC GND return
Pin 5 +24 VDC power
Pin 6 Chassis GND / Earth GND
6
Copyright © SpectraDynamics, Inc. 2010
