Owner's Guide and Installation Manual
Camille
Camille
Camille

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Camille and is the answer not in the manual?

Questions and answers

Related Manuals for Hunter Camille

Summary of Contents for Hunter Camille

  • Page 1 Warranty Assistance For reference, also attach your receipt or a copy of your receipt to the manual. Owner’s Guide and Installation Manual __________________________________________ Model Name __________________________________________ Model No. __________________________________________ Date Purchased __________________________________________ Where Purchased Form M0022-01 20120910 ©2012 Hunter Fan Co.

  • Page 2: Table Of Contents

    Bowl Light Fixture ....13 use a solid-state speed control with this fan. Use only Hunter speed 9 • Operating and Cleaning Your Ceiling controls, which are solid state.
  • Page 3 If you want to use an existing fan site, complete the following checklist to determine Suitable Existing Fan Site if the site is acceptable and safe for your new Hunter fan. If you cannot check off Fan Support every item, prepare a new fan site as described on this page.
  • Page 4 Section 2 • Installing the electrical codes and ANSI/NFPA 70. If Ceiling Plate. you are unfamiliar with wiring, use a qualified electrician. M0022-01 • 09/10/12 • Hunter Fan Company...
  • Page 5 Support Brace Hunter’s patented 2-position mounting system provides you maximum installation flexibility and ease. You can install your Hunter fan in one of two ways, depending on ceiling height and your preference: Standard or Angled mounting. The steps in this manual include instructions for Ceiling both Installer’s Choice mounting methods.

  • Page 6: Getting Ready

    • Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: •...

  • Page 7: Installing The Ceiling Bracket

    2-5. Tighten the screws into the 9/64” pilot holes; do not use lubricants Steps 2-3 – 2-5 on the screws. Do not over tighten. Flat Washer 3” Wood Screw M0022-01 • 09/10/12 • Hunter Fan Company...

  • Page 8: Assembling And Hanging The Fan

    For angled ceilings, point least 8” extending from the top of the downrod. opening toward peak 3-6. Raise the fan and place the downrod ball into the ceiling bracket. Ceiling Bracket Downrod Step 3-6 M0022-01 • 09/10/12 • Hunter Fan Company...

  • Page 9: System

    4-8. Return to the fan so you can complete the fan wiring. Steps 4-6 – 4-7 Steps 4-2 – 4-3 Steps 4-4 – 4-5 3mm (1/8") Support Brace Outlet Box Braided Ceiling Cable M0022-01 • 09/10/12 • Hunter Fan Company...

  • Page 10: Wiring The Fan

    • The black wire from the fan to the black wire from the receiver (marked on red tag “FAN OUT”) • The white wire from the fan to the white wire from the receiver (marked on red tag “COMMON OUT”) Wire Connector Step 5-4 M0022-01 • 09/10/12 • Hunter Fan Company...

  • Page 11: Installing The Canopy

    6-1. Raise the canopy over the ceiling bracket and align the two holes of the canopy and the ceiling bracket. 6-2. Insert and tighten the canopy screws securely. Canopy Hanger Screw Bracket Canopy Screw Canopy Steps 6-2 Step 6-1 M0022-01 • 09/10/12 • Hunter Fan Company...

  • Page 12: Assembling The Blades

    7-2. Install one blade onto a blade iron with three blade assembly screws. 7-3. Repeat Steps 8-1 8-2 until all three blades are installed. – Grommet Steps 7-1 – 7-2 Blade Assembly Screw M0022-01 • 09/10/12 • Hunter Fan Company...

  • Page 13: Completing Your Installation With A Bowl Light Fixture

    8-4. Install a third housing assembly screw into the remaining screw hole in the shroud. Securely tighten all three screws. 8-5. Install six #6-32 machine screws into the outer holes in the shroud. Step 8-4 Housing Shroud Assembly Screw Step 8-5 M0022-01 • 09/10/12 • Hunter Fan Company...
  • Page 14 Exceeding the wattage limit marked on the MAX wattage sticker affixed to the light socket(s) may result in fire hazard or improper operation. M0022-01 • 09/10/12 • Hunter Fan Company...
  • Page 15 8-13. Attach the extra pull chains with pendants (included) to the light and fan pull chains using the breakaway connector. (You may find the breakaway connector on the end of the extra chains.) Step 8-10 Breakaway Connector Steps 8-10 – 8-11 M0022-01 • 09/10/12 • Hunter Fan Company...

  • Page 16: Fan

    Unscrew the cap at the bottom of the glass globe and remove the cap, finial, and glass shade. Slide the Reversing reversing switch on the fan to the opposite position. Switch After reinstalling glass, finial, and cap, restart fan. M0022-01 • 09/10/12 • Hunter Fan Company...

  • Page 17: Troubleshooting

    If you need parts or service assistance, please call 888-830-1326 (In Canada, call 866-268-1936) or visit us at our website at http://www.HunterFan.com. Hunter Fan Company 7130 Goodlett Farms Parkway #400 Memphis, Tennessee 38016 M0022-01 • 09/10/12 • Hunter Fan Company...
