Dimensions & Specifications - HAMPTON BAY GC60 Owner's Manual

d :
imenSionS
4" Exhaust
S
peciFicationS
Input rating when using: Wood Pellets/Corn - 55,000BTU (16.1KW•hr) & Wheat/Barley - 53,000BTU (15.5KW•hr).
Description
Residential Pellet Heater
Voltage
110 - 120 V
Frequency
60 Hz
Testing Standard
ASTM 1509-04
*Note: Consumption will vary with the type and quality of pellets / fuel used.
Hampton GC60 Cast Pellet Stove Owner's Manual
Specifications
23"
(584mm)
29.4"
(748mm)
28.4"
(722mm)
:
Fuel type
6mm (¼") dia. Pellets - wood, corn, wheat, & barley*
Current
4.2 Amps
Hopper Capacity
up to 60 lb (36.3 Kg)
Weight (with full hopper)
485 lb (220 Kg)
3" Fresh Air Intake
28.7"
(729mm)
31.7"
(806mm)
figure 1: dimensions of Gc60.
Table 1: GC60 Specifications.
28"
(713mm)
4" Exhaust
18.5"
(470mm)
Max Power
504 Watts
Consumption on Low
1.5 lb/hr (0.68 Kg/hr)*
Consumption on High
6.5 lb/hr (2.95 Kg/hr)*
