Service Procedures (cont.)
Remove the InfoKey Controller Dock
Tool Required: 3 mm hex wrench, torque wrench with 3 mm bit
To remove the InfoKey Controller Dock:
1.
Make sure the Segway PT is unplugged and powered off.
2.
Using a 3 mm hex wrench, remove the fastener holding the InfoKey
Controller Dock to the LeanSteer Frame.
3.
Remove the InfoKey Controller Dock.
Install/Remove the Dock Adapter
Tool Required: None
To install the InfoKey Controller Dock Adapter, screw the adapter to the
underside of the InfoKey Controller. When installed properly, the Dock
Adapter should snap into place when screwed on.
To remove the InfoKey Controller Dock Adapter, unscrew the adapter from
the underside of the InfoKey Controller.
116
Figure 77: Remove the InfoKey Controller Dock
