Summary of Contents for Growatt 2000HF
- Page 1 Growatt 2000HF Growatt 2500HF Growatt 3000HF Installation & Operation Manual GROWATT NEW ENERGY CO., LTD No.12 Building, Xicheng Industrial Zone, Bao’an District, Shenzhen, P. R.China + 86 755 2747 1900 + 86 755 2749 1460 service@ginverter.com www.ginverter.com GR - UM - 006 - 03...
- Page 2 1.4 Safety Unpacking 2.1 Unpacking and Inspection 2.2 Information of Label Mounting 3.1 Selecting Mounting Location 3.2 Dimensions and Required Clearances 3.3 Mounting the Bracket 3.4 Mounting Growatt HF Electrical Connections 4.1 Wiring AC Output 4.2 Wiring DC Input Commissioning...
- Page 3 7.2 LCD control 7.3 Setting of the LCD display With this installation guide, users are able to install and operate the Growatt HF inverters easily. This manual does not cover any details concerning about equipment connected to the Growatt HF. Store this manual where accessible at all times.
- Page 4 (Download link: www.ginverter.com) Notes : Because of the high frequency transformer isolation and wide input voltage range, Growatt HF is very suitable for thin-film systems or any other PV systems that requires NEGATIVE GROUND or GALVANIC ISOLATION. Fig 1.1 Front and Bottom Overview: 1.4 Safety...
-
Page 5: Information Of Label
Possible damage the PV modules as a result of Identification of String Failure! 1( Optional) Bluetooth H(Optional) The Growatt HF Inverter is equipped with a system which recognizes total failure of individual strings or part-strings. Notes : Though the packaging box of Growatt HF is durable, please treat the packing box softly and avoid disposing the packing box. - Page 6 The Ingress Protection rate (IP level) is IP65 which means Growatt Do not install Growatt HF in living area, the noise caused by HF can be installed both indoors and outdoors. inverter might affect on daily life.
-
Page 7: Mounting The Bracket
3.3 Mounting the Bracket 3.4 Mounting Growatt HF To install Growatt HF on the wall, installers should mount the bracket to the wall After the bracket is firmly mounted on the wall, then install Growatt HF onto the firmly as the first step. -
Page 8: Electrical Connections
AWG no. Model Area(mm²) _(mm) Connect the positive and negative terminal from the PV panels to positive and negative terminal on the PV inverter. The maximum string currents are varying 2000HF _2.05 3.332 from different inverter types; 2500HF _2.05 3.332 3000HF _2.05... -
Page 9: Operation Modes
Growatt HF automatically stop running during periods of little or no sunlight. In That is the power fed to the grid. The LED turns green. shutdown mode Growatt HF won’t take any power from the grid or panels, and LCD and LED turns off. -
Page 10: Display And Messages
Display and Messages STATUS DISPLAY CONTENT REMARK 7.1 LCD display Once the PV power is sufficient, inverter displays information as the following Fault Error: xxx System fault sequence. Auto Test Auto Testing Protecting functions' auto test Programming Programming Firmware update Notes: In fault mode, there can be different error messages displayed in the LCD due to different faults. -
Page 11: Parameters Setting
CYCLE DISPLAY DISPLAY TIME/S REMARK 7.2 LCD control To save power, the LCD display’s background light will turn off automatically in 10 seconds. Single knock will turn on the background light. The display on the inverter Total generated energy can be controlled by knocking the sound control panel in front of it. since installation PV input power PV voltage (PV) and... - Page 12 Password is ftpguest 8.1 ShineNet ShineNet is a monitoring software applied to monitor Growatt inverters via RS232 port or Bluetooth module. With the special designed functions and friendly compact UI, it can comprehensively meet users’ requirements for system monitoring and bring unprecedented user experience.
- Page 13 Collects data and uploads information over the internet in near real-time Power supply option: built-in battery slot, an external DC power supply. to Growatt Shine Server platform. Easy installation, and convenient to use it. Connect with inverter: RS485 and Zigbee (Wireless module).
-
Page 14: Troubleshooting
An error message will be displayed on the LCD screen when a fault occurs. The faults consist of system fault and inverter fault. You may be advised to contact Growatt in some situation, please provide the following information. Information concerning the inverter: •... -
Page 15: Inverter Fault
The reason replacement, check utility grid. be less than 100Ω.2. If panels can be utility grid voltage If you require help, contact Growatt. PV+ is grounded, check the or frequency change 3.If error message still exists, impedance between the earth and frequently. -
Page 16: Specifications
Specifications Growatt 2000HF Growatt 2500HF Growatt 3000HF Growatt 2000HF Growatt 2500HF Growatt 3000HF Input Data General Data Max. DC power 2200W 2700W 3200W Dimensions (W / H / D) in mm 440 / 455 / 135 440 / 455 / 135 440 / 455 / 135 Max. -
Page 17: Growatt Factory Warranty
Growatt12000UE, Growatt18000UE, and Growatt 20000UE. For the above named products, you receive a Growatt factory warranty valid for 5 years from the date of installation and no more than five and a half years from the In the latter case, the remainder of the warranty entitlement will be transferred to the replacement device. - Page 18 Contact If you have technical problems concerning our products, contact your installer or Growatt. During inquiring, please provide below information: Inverter type Modules information Communication method Serial number of Inverters Error code of Inverters Display of inverters...
