Section
8
Panel Size
Type
Resolution Capabilities
Pixel Pitch
Active Display Area
Pixel Format
Viewing Angle (Left/Right)
Viewing Angle (Up/Down)
Contrast Ratio
Brightness
Response Time
Back Lights
Video Connector
Colors Supported
Video Input
Sync
Input Voltage
Power consumption
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Operating Altitude
Storage Altitude
VT150 DiamondVue Series User Guide
ENGINEERING SPECIFICATIONS
15.0"
TFT Active matrix w/ Anti-Glare coating
VGA to SXGA
0.297mm
150M / 150W:
11.97" x 8.95" / 304mm x 227mm
150PI / 150P / 150P-SS / 150R:
12.11" x 9.12" / 307.59mm x 231.65mm
640 x 480, 800 x 600, 1024 x 768, 1280 x 1024
70/70º
65/70º
300:1
150P, 150R, 150PSS, 150W, 150M, 150PI:
450 Nits
Transflectives:
over 1000 Nits*
T
= 5ms typical
R
T
= 20ms typical
F
Cold Cathode 50,000 Hrs. Half Life
HD15(F); Composite Video (CVSC); S-Video (S-VHS)
16.2M
RGB Analog (0.7V p-p / 75ohm) , Digital
NTSC / PAL, CVBS (1.0V p-p)
S-VHS, luma/chroma (.7V p-p / 75ohm)
Separate H&V, Combined,
SOG (Sync On Green), Digital
AC 100-240V 50/60Hz 1.0A
Normal: 35Watts DPMS: < 5Watts
0 to 50ºC
-20 to 60ºC
10 to 95%NC
10 to 95%NC
Up to 10,000 ft
Up to 40,000 ft
*Outdoor Brightness Equivalent (Varies depending upon sunlight brightness)
21
SPECIFICATIONS
SPECIFICATIONS
150-005
