SECTION 8
•
TRANSISTOR AND FET'S
2SA1576A R
(Symbol: FR)
B
C
E
2SC3775 3
(Symbol: OY3)
B
C
E
2SK1069-4
(Symbol: FJ)
S
G
D
DTC144 EUA
(Symbol: 26)
B
C
E
•
DIODES
1SS355
(Symbol: A)
A C
HSM88ASR
(Symbol: C3)
C
A
SEMI-CONDUCTOR INFORMATION
2SA1577 Q
(Symbol: HQ)
B
C
E
2SC4081 R
(Symbol: BR)
B
C
E
3SK131-T2-LA
(Symbol: V12)
G1 S
G2 D
FMW1
(Symbol: W1)
B1 C1
E
B2
C2
1SS375
(Symbol: FH)
A
C
HVC350BTRF
(Symbol: B0)
A C
2SA1588 GR
(Symbol: ZG)
B
C
E
2SC4215 O
2SC4116 BL
(Symbol: QO)
(Symbol: LL)
B
C
E
DTA144 EUA
DTA114 EUA
(Symbol: 16)
(Symbol: 14)
B
C
E
1SV214 DA204 U
(Symbol: T1) (Symbol: K)
pink
A C
MA77 MA8062-M
(Symbol: 4B) (Symbol: 6-2)
A C
8 - 1
2SB1132 R 2SC2714 Y
(Symbol: BAR) (Symbol: QY)
B
C
E
2SC4226 R25
(Symbol: R25)
B
C
E
DTC114 EUA
(Symbol: 24)
B
C
E
DA204 K DSA3A1
(Symbol: K) (Symbol: Green)
A
C
XB15A308
(Symbol: T8)
A C
B
C
E
B
C
E
B
C
E
Green
A
C
A
C
