Icom IC-M401E Service Manual page 21

[LOGIC-E BOARD]
REF ORDER
NO. NO.
R62 7030003560 S.RESISTOR
R63 7030003490 S.RESISTOR
R64 7030003800 S.RESISTOR
R65 7030003680 S.RESISTOR
R71 7030003640 S.RESISTOR
R72 7030003520 S.RESISTOR
R73 7030003280 S.RESISTOR
R75 7030003680 S.RESISTOR
R77 7030003400 S.RESISTOR
R78 7030003540 S.RESISTOR
R81 7030003620 S.RESISTOR
R82 7030003680 S.RESISTOR
R83 7030003560 S.RESISTOR
R84 7030003700 S.RESISTOR
R85 7030003640 S.RESISTOR
R86 7030003680 S.RESISTOR
R87 7030003680 S.RESISTOR
R88 7030003680 S.RESISTOR
R90 7030003440 S.RESISTOR
C1 4030007060 S.CERAMIC
C2 4030009650 S.CERAMIC
C3 4030008890 S.CERAMIC
C5 4030006900 S.CERAMIC
C6 4030006900 S.CERAMIC
C7 4550006210 S.TANTALUM
C8 4030006900 S.CERAMIC
C9 4030006900 S.CERAMIC
C11 4030006860 S.CERAMIC
C12 4030006900 S.CERAMIC
C41 4550006210 S.TANTALUM
C42 4030006900 S.CERAMIC
C43 4030006900 S.CERAMIC
C44 4030006860 S.CERAMIC
C72 4030006900 S.CERAMIC
C73 4030006900 S.CERAMIC
C74 4030006900 S.CERAMIC
C75 4030006880 S.CERAMIC
C76 4030006900 S.CERAMIC
C81 4030006860 S.CERAMIC
C82 4030006900 S.CERAMIC
C91 4030006860 S.CERAMIC
C92 4030006860 S.CERAMIC
C93 4030006860 S.CERAMIC
C94 4030006850 S.CERAMIC
C95 4030006860 S.CERAMIC
C96 4030006850 S.CERAMIC
J1 6510021440 S.CONNECTOR
J3 6510022190 S.CONNECTOR
J4 6510022470 S.CONNECTOR
DS1 5030001950 LCD
DS2 5040002310 S.LED
DS3 5040002310 S.LED
DS4 5040002310 S.LED
DS5 5040002310 S.LED
DS6 5040002660 S.LED
DS7 5040002660 S.LED
EP1 0910056810 PCB
EP2 8930054970 LCD CONTACT
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
C1608 CH 1H 270J-T
C1608 CH 1H 240J-T
C1608 JB 1H 273K-T
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
ECST1CX106R
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
ECST1CX106R
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
C1608 JB 1H 472K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
B6B-ZR-SM3-TF
B3B-PH-SM3-TB
40FLT-SM1-TB
TTR5341
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
FY1101F-TR (LED)
FY1101F-TR (LED)
B 6054
SRCN-2438-SP-N-W
[VR BOARD]
REF ORDER
NO. NO.
T R1 7210002350 VARIABLE
T
T
T W1 8900010820 CABLE
T
T
T EP1 0910056781 PCB
T
T
T
T
T
T
[SQL BOARD]
T
T
REF ORDER
T
NO. NO.
T
T
T R1 7210002360 VARIABLE
T EP1 0910056791 PCB
T
T
T
T
T
T
[FRONT UNIT]
T
T
REF ORDER
T
NO. NO.
T
T
T MC1 0800006232 MICROPHONE
T MC1 0800006242 MICROPHONE
T
T
T SP1 2510001240 SPEAKER
T
T
T W1 7120000470 JUMPER
T W2 7120000470 JUMPER
T W3 8900010500 CABLE
T
T
T
T
T
[CHASSIS UNIT]
T
REF ORDER
T
NO. NO.
T
C1 4020000430 CYLINDER
B
B
B J1 6510004880 CONNECTOR
B
B
B W1 8900010710 CABLE
B W2 8900010491 CABLE
W3 7120000470 JUMPER
B
6 - 5
DESCRIPTION M.
TP96N97N15F-10KA-1301
OPC-1099 <CMI>
B 6051A
DESCRIPTION M.
TP96N97-15F-10KB-1301
B 6052A
DESCRIPTION M.
HM-132B-2 ACC <KN> [BLACK]
HM-132W-2 ACC <KN> [WHITE
045P0803 <FG>
ERDS2T0
ERDS2T0
OPC-1046
DESCRIPTION M.
UP050 B 471K-NA-CZ
MR-DS-E 01
OPC-1087 <LIA>
OPC-1041A
ERDS2T0
S.=Surface mount
