Icom IC-M401E Service Manual page 22

6-2 HM-132
[MAIN UNIT]
REF ORDER
NO. NO.
R1 7010007640 RESISTOR
R2 7010007630 RESISTOR
R3 7010007650 RESISTOR
R4 7010007660 RESISTOR
C1 4030018550 S.CERAMIC
C2 4030011340 S.CERAMIC
MC1 7700002500 MICROPHONE
S1 2260002330 SWITCH
S2 2260002340 SWITCH
S3 2260002340 SWITCH
S4 2260002340 SWITCH
W1 9018490010 WIRE
W2 9018490010 WIRE
W3 9024495010 WIRE
W4 9024495020 WIRE
EP1 0910053701 PCB
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
FRD25 T2-123J (12 kΩ)
FRD25 T2-682J (6.8 kΩ)
FRD25 T2-153J (15 kΩ)
FRD25 T2-333J (33 kΩ)
C1608 JB 1H 223K-T
C1608 CH 1H 471J-T
KUC3523-040245
SKHHLP014A
SKHHAM024A
SKHHAM024A
SKHHAM024A
71/98/010/X98/X98 <KN>
71/98/010/X98/X98 <KN>
24/00/020/W01/W01 <KN>
24/04/020/W01/W01 <KN>
B-5587A
S.=Surface mount
T
T
T
T
T
B
B
T
T
T
T
T
B
B
6 - 6
