4 Pin Main Harness
1
2
3
4
6 Pin Start Harness
1
2
3
4
5
6
6 Pin Output Harness
2010 Audiovox Electronics Corporation. All rights reserved.
WHITE/RED
WHITE
BLACK
BROWN
PURPLE
RED
ORANGE
PINK/WHITE
RED/WHITE
PINK
PARKING LIGHT INPUT
PARKING LIGHT OUTPUT
GROUND
SIREN OUTPUT ( + )
STARTER OUTPUT - MOTOR SIDE
BATTERY 12V ( + )
ACCESSORY 1 ( + )
IGNITION 2 ( + )
BATTERY 12V ( + )
IGNITION 1 ( + )
5
