2
GREEN
Locate the vehicle's dome light or door pin switch wire.
Verification: This wire will register ground (NEG) when the door is opened
and the interior light is on. This wire will register positive voltage when the
door is closed and the interior light is off.
Connect the GREEN wire to the vehicle's negative door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide.
3
PURPLE
Locate the vehicle's dome light or door pin switch wire.
Verification: This wire will register positive voltage (POS) when the door is
opened and the interior light is on. This wire will
register ground or "0" Volts when the door is closed and the interior light is
off.
Connect the PURPLE wire to the vehicle's positive door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide.
4
WHITE/BLUE
This wire will activate the Remote Start function when a GROUND pulse is applied to it
from an external device.
5
GRAY
Install a Hood Pin Switch and connect to the GRAY wire. This connection is
required for Remote Start.
Verification: This wire when connected will register ground when the
vehicle's hood is opened.
Connect the GRAY wire to the hood pin.
NOTE: Be sure to loom the wire, and seal the grommet.
12
DOOR TRIGGER INPUT ( - )
DOOR TRIGGER INPUT ( + )
EXTERNAL START INPUT ( - )
HOOD PIN INPUT ( - )
