Installation and Operation (cont.)
Enclosure dimensions
CVDA 6 MX, CVDA 6 MX Dual, AVDA 6 MX, SVDA 6 MX, SADA 6
MX, SADA 6 MX Dual
1.75" H x 8.75" W x 9.4" D (1U high, half
rack width)
4.4 cm H x 22.2 cm W x 23.9 cm D
(Depth excludes connectors and knobs.)
CVDA 6 MX Quad, AVDA 6 MX Dual, SADA 6 MX Quad
1.75" H x 17.5" W x 9.4" D (1U high, full
rack width)
4.4 cm H x 44.5 W x 23.9 cm D
(Depth excludes connectors and knobs.)
Product weight
SVDA 6 MX, SADA 6 MX 2.3 lbs (1.0 kg)
CVDA 6 MX, SADA 6 MX Dual
2.5 lbs (1.1 kg)
CVDA 6 MX Dual ............ 2.9 lbs (1.3 kg)
CVDA 6 MX Quad ........... 5.2 lbs (2.4 kg)
AVDA 6 MX ...................... 2.7 lbs (1.2 kg)
SADA 6 MX Quad ............ 4.5 lbs (2.0 kg)
AVDA 6 MX Dual ............ 4.8 lbs (2.2 kg)
Shipping weight
CVDA 6 MX, CVDA 6 MX Dual, AVDA 6 MX, SVDA 6 MX, SADA 6
MX, SADA 6 MX Dual
5 lbs (2.3 kg)
CVDA 6 MX Quad, SADA 6 MX Quad
8 lbs (3.6 kg)
AVDA 6 MX Dual ............ 7 lbs (3.2 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International
Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
6
Extron • Audio/Video Distribution Amplifiers
Extron • Audio/Video Distribution Amplifiers
7
