Code Alarm ca 5152 Installation Manual page 25

Feature Bank 5 - 4 Pin Alternate Output Control
1 - Lt Green/Black Output : Controls the LT GREEN/BLACK output activation
type and timing.
Pulse before Start / During Unlock - 1 second pulse when remote start is
activated. Also a 1 second pulse when unlock is pressed.
Ground While Running - Continuous output for the entire remote start
sequence until after the vehicle shuts down.
Ignition - Output becomes active with the same timing as the ignition output
and does not drop out during crank.
Accessory - Output becomes active with the same timing as the accessory
output, drops out during crank.
Pulse During Crank - Output becomes active with the same timing as the
starter output wire, during crank only.
2 - Lt Blue Output : Controls the LT BLUE output activation type and timing.
Pulse After Start / During Lock - 1 second pulse after the remote start
sequence and has confirmed the vehicle is running. Also a 1 second pulse
when unlock is pressed.
Ground While Running - Continuous output for the entire remote start
sequence until after the vehicle shuts down.
Ignition - Output becomes active with the same timing as the ignition output
and does not drop out during crank.
Accessory - Output becomes active with the same timing as the accessory
output, drops out during crank.
Pulse During Crank - Output becomes active with the same timing as the
starter output wire, during crank only.
3 - Green/White Output : Controls the GREEN/WHITE output activation type and
timing.
Pulse After Shutdown - 1 second pulse after the remote start has
shutdown.
Ground While Running - Continuous output for the entire remote start
sequence until after the vehicle shuts down.
Ignition - Output becomes active with the same timing as the ignition output
and does not drop out during crank.
Accessory - Output becomes active with the same timing as the accessory
output, drops out during crank.
Pulse During Crank - Output becomes active with the same timing as the
starter output wire, during crank only.
ca5152. 2011 Audiovox Electronics Corporation. All rights reserved. 25
