10 Pin Main Harness

1 BLUE/GREEN
This wire provides a ( - ) 200mA output upon the second press of unlock. This
output is used unlock the remaining passenger doors when the system is set up
for driver priority unlock.
2 BLACK/WHITE
This wire provides a ( - ) 200mA output for 30 seconds when the system is
disarmed capable of driving relays.
Locate the vehicle's dome light or pin switch wire.
Verification: This wire will register positive voltage or ground when the
vehicle's dome light is turned ON.
3 WHITE/RED
4 WHITE
Locate the parking light output wire at the vehicle's light switch.
Verification: This wire registers positive voltage when the parking lights
are turned on.
Positive switching Parking Lights:
Connect the WHITE/RED wire to a 15 Amp max fused battery source.
Connect the WHITE wire to the parking light output wire.
Negative switching Parking Lights:
Connect the WHITE/RED wire to a good chassis ground.
Connect the WHITE wire to the parking light output wire.
