10 Pin Main Harness
1
2
3
4
5
6
7
8
9
10
6 Pin Door Lock Harness
4
BLUE/GREEN
BLACK/WHITE
WHITE/RED
WHITE
BLACK
ORANGE
RED
BROWN/BLACK
YELLOW
RED/WHITE
2ND UNLOCK OUTPUT ( - )
ILLUMINATED ENTRY OUTPUT ( - )
PARKING LIGHT INPUT
PARKING LIGHT OUTPUT
GROUND
GROUND WHEN ARMED OUTPUT ( - )
BATTERY 12V ( + )
HORN OUTPUT ( - )
IGNITION INPUT ( + )
TRUNK RELEASE OUTPUT ( - )
ca2051 rev B. 2011 Audiovox Electronics Corporation. All rights reserved.
