  • Page 1 PROFESSIONAL SERIES Security and Keyless Entry Installation Guide CA 1050 2009 Audiovox Electronics Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Table of Contents Before You Begin ..................3 Wire Connection Guide ................4 5 Pin Main Harness ................... 5 6 Pin Input / Output Harness ..............6 2 Pin Door Lock Output Harness ............. 8 Additional Ports ..................12 LED Port ....................12 Programming Port ..................

  • Page 3: Before You Begin

    BEFORE YOU BEGIN PROFESSIONAL INSTALLATION STRONGLY RECOMMENDED Installation Precautions: Roll down window to avoid locking keys in vehicle during installation Avoid mounting components or routing wires near hot surfaces Avoid mounting components or routing wires near moving parts Tape or loom wires under hood for protection and appearance Use grommets when routing wires through metal surfaces...

  • Page 4: Pin Main Harness

    5 Pin Main Harness 6 Pin Input / Output Harness 2 Pin Door Lock Output Harness 2009 Audiovox Electronics Corporation. All rights reserved.

  • Page 5: Pin Main Harness

    5 Pin Main Harness WHITE/RED PARKING LIGHT INPUT WHITE PARKING LIGHT OUTPUT Locate the parking light output wire at the vehicle’s light switch. Verification: This wire registers positive voltage when the parking lights are turned on. Positive switching Parking Lights: Connect the WHITE/RED wire to a 15 Amp max fused battery source.
  • Page 6 BATTERY 12V ( + ) Locate 1 of the vehicle’s constant 12 Volt battery wires at the ignition switch. Verification: This wire will register ( + ) voltage in all positions of the ignition switch. Connect the RED wire to the constant 12 Volt battery wire. NOTE: Remove all fuses until all connections are made.
  • Page 7 GREEN DOOR TRIGGER INPUT ( - ) Locate the vehicle’s dome light or door pin switch wire. Verification: This wire will register ground (NEG) when the door is opened and the interior light is on. This wire will register positive voltage when the door is closed and the interior light is off.

  • Page 8: Pin Door Lock Output Harness

    2 Pin Lock Output Harness BLUE UNLOCK ( - ) GREEN LOCK ( - ) The door lock / unlock outputs are designed to control several different types of systems which may require additional parts. Please review the wire and location chart to see which type of door lock system is in your vehicle.
  • Page 9 Positive Switching Locks All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock switch. Verification: These wires will register positive voltage when the Lock and Unlock switches are activated. Connect the GREEN and BLUE wires shown in the diagram below. Positive Locks: Fused +12 Volt Battery Souce...
  • Page 10 Negative Multiplexed Locks All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock switch. Verification: This wire will show variable ground when the switch is activated. Please consult the wire and location chart for specific resistor values for your vehicle.
  • Page 11 Adding Aftermarket Actuators After installing aftermarket actuators, (not supplied). Connect the GREEN and BLUE wires shown in the diagram below using (2) SPDT relays (not supplied). Fused +12 Volt Battery Source Door Lock GREEN (-) Lock Output Actuator Chassis Ground Fused +12 Volt Battery Source BLUE (-) Unlock Output...

  • Page 12: Additional Ports

    Additional Ports LED Port The LED included in the kit will serve as a visual indicator of the alarm’s status. It should be installed in the dash, located where it can be easily seen from outside the vehicle, yet not be distracting to the driver. Once a location has been selected, check behind the panel for wire routing access, and to confirm the drill will not damage any existing components as it passes through the panel.

  • Page 13: Set Up & Programming

    Set Up & Programming Transmitter Programming - Feature Bank 1 1. Turn the ignition ON. 2. Press and hold the valet/override button. 3. Within 10 seconds the system will chirp (3) three times. 4. Press 1 button of each transmitter you wish to program. 5.

  • Page 14: Transmitter Programming

    Feature Bank 1 - 3 Chirps Transmitter Programming Refer to transmitter programming. Feature Bank 4 - Shock Sensor Adjustment 1. Enter Feature Bank 4 2. Press and release to select full trigger. 3. Use to adjust the settings. The system will give short chirps upon each press.

  • Page 15: Programming Feature Banks

    Chirp Delete - User Accessible System ARM/DISARM chirps can be toggled ON or OFF without entering the programming feature banks. 1. Turn the ignition ON then OFF. 2. Press and release the valet/programming button 3 times. The system will respond with 1 chirp for ON or 2 chirps for OFF. Dome Light Delay / Theater Dimming The system can be programed to delay arming after the lock button is pressed (60 second max) for vehicles with a dome light delay or theater dimming feature.
  • Page 16 2 - Passive Locks: Determines manual or automatic locking of the vehicle’s doors. Active - Requires use of the transmitter to lock the vehicle’s doors. Passive - Automatically locks the vehicle’s doors 1 minute after the last door is closed 3 - Passive Arming: Determines manual or automatic locking of the vehicle’s doors.

  • Page 17: Transmitter Button Functions

    Transmitter Button Functions Security Trigger Zones If the security system has been triggered the LED will flash one of the patterns below indicating the zone. LED FLASHES TRIGGER ZONE 2 Flashes Hood / Trunk Input 3 Flashes Door Input 4 Flashes Shock Sensor 5 Flashes Ignition Input...
  • Page 18 2009 Audiovox Electronics Corporation. All rights reserved.
  • Page 19 2009 Audiovox Electronics Corporation. All rights reserved.
  • Page 20 Audiovox Electronics Corporation. Customer Service 1-800-421-3209 WWW.CODE-ALARM.COM FCC COMPLIANCE This device complies with Part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2.
