INSTALLATION INSTRUCTIONS

HD44CC5
High Definition Video Matrix Switcher,
Coaxial and CAT5
DESCRIPTION
The HD44CC5 four-source, four-zone high-definition matrix switcher has component video and
S/PDIF digital audio inputs for each source. All four zone outputs have component video output and
S/PDIF audio output for economical local distribution up to 250', as well as a RJ45 output for
transmission of the video and digital audio signal up to 1000' to the HDRXSG01 receiver located in
the zone. Both coaxial component video output and CAT5 output are active simultaneously, making it
possible to distribute four sources to eight outputs at the same time.
The HD44C has the same great features as the HD44CC5 without the CAT5 output. The HD44C is
ideal for installations requiring local switching and distribution up to 250'.
The HD44CC5 and HD44C unit is expandable up to 16 zones.
SPECIFICATIONS
Size: 17" W x 7 3/8" D x 3 15/16" H
Weight: 9.25 lbs (4.2 kilos)
Controllable through IR and RS232 commands
Bandwidth supports resolutions of 1080p, 1080i, 720p, 480p and 480i.
Optional Rack Mount kit available (RM2UKIT)
Power supply (120VAC, 0.25A, 50-60Hz)
Operates in temperatures up to 55 degrees Celsius.
08905071A
HD44C
High Definition Video Matrix Switcher,
Coaxial Only
- 1 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the HD44CC5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Xantech HD44CC5

Summary of Contents for Xantech HD44CC5

  • Page 1: Installation Instructions

    The HD44C has the same great features as the HD44CC5 without the CAT5 output. The HD44C is ideal for installations requiring local switching and distribution up to 250’.
  • Page 2 DETAIL OVERVIEW [1] SOURCE LOOP-THROUGH CONNECTION The source inputs are buffered to provide an output at the same levels, assuming a 75-ohm termination is on the output. Use these connections for HD44 expansion systems. The buffers are an active circuit. The HD44 must be powered on for an active connection. [2] SOURCE INPUTS Gold-plated RCA jacks for connection from the output of the source.
  • Page 3 RING GROUND SLEEVE +12VDC, 25mA [4] IR BUS, EMITTER PORT The 3.5mm Mono jack is an emitter port. The IR signal is connected to the IR Receiver. A Xantech 283M emitter can be connected to this port. PLUG CIRCUIT IR SIGNAL SLEEVE GROUND The 2-Pin WECO screw terminal is an IR port.
  • Page 4 (120VAC type) or international (240VAC type). [7] RS232 EXPANSION The HD44C and HD44CC5 can be expanded into a larger system. By using any combination of the HD44C and HD44CC5 (up to 8 systems), a larger High-Definition distribution system can be created.

  • Page 5: Important Notice

    If for some reason the system losses power at the receiving end (HDRXSG01), the transmitting end (HD44CC5), or both ends, the full self-calibration process will automatically occur. 08905071A...
  • Page 6 [1] Connect the High-Definition Source to the HD44CC5 or HDTXSG01. Figure 1 below shows a HD44CC5 (video matrix transmitter) connected to the HDRXSG01 (receiver). [2] Using CAT5 cable, connect the HD44CC5 zone output or the output from the HDTXSG01 to the HDRXSG01. Connect power to the HD44CC5 first. Then connect power to the HDRXSG01.
  • Page 7 RC68+ (IR) COMMANDS The RC68+ should be set to Group Code “C0”. ZONE 1 ZONE 2 ZONE 3 ZONE 4 Zone Power Toggle SRC 1 SRC 2 SRC 3 SRC 4 Zone 1 Source Select Zone 2 Source Select Zone 3 Source Select Zone 4 Source Select ZONE 1 ZONE 2...
  • Page 8 HD content to areas such as outdoor patios and pool table recreational areas. FIGURE 2 FIGURE 3: The figure in the next page shows an expanded HD44CC5 system. With two HD44CC5 devices, HD content can be distributed to 16 displays (8 with CAT5 outputs, 8 with coaxial outputs).
  • Page 9 FIGURE 3 08905071A - 9 -...
  • Page 12 This document is copyright protected. No part of this manual may be copied or reproduced in any form without prior written consent from Xantech Corporation. Xantech Corporation shall not be liable for operational, technical, or editorial errors/omissions made in this document. Document Number 08905071A...
