INSTALLATION INSTRUCTIONS

HD44CC5
High Definition Video Matrix Switcher,
Coaxial and CAT5
DESCRIPTION
The HD44CC5 four-source, four-zone high-definition matrix switcher has component video and
S/PDIF digital audio inputs for each source. All four zone outputs have component video output and
S/PDIF audio output for economical local distribution up to 250', as well as a RJ45 output for
transmission of the video and digital audio signal up to 1000' to the HDRXSG01 receiver located in
the zone. Both coaxial component video output and CAT5 output are active simultaneously, making it
possible to distribute four sources to eight outputs at the same time.
The HD44C has the same great features as the HD44CC5 without the CAT5 output. The HD44C is
ideal for installations requiring local switching and distribution up to 250'.
The HD44CC5 and HD44C unit is expandable up to 16 zones.
SPECIFICATIONS
Size: 17" W x 7 3/8" D x 3 15/16" H
Weight: 9.25 lbs (4.2 kilos)
Controllable through IR and RS232 commands
Bandwidth supports resolutions of 1080p, 1080i, 720p, 480p and 480i.
Optional Rack Mount kit available (RM2UKIT)
Power supply (120VAC, 0.25A, 50-60Hz)
Operates in temperatures up to 55 degrees Celsius.
08905071B
HD44C
High Definition Video Matrix Switcher,
Coaxial Only
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD44C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Xantech HD44C

Summary of Contents for Xantech HD44C

  • Page 1: Installation Instructions

    The HD44C has the same great features as the HD44CC5 without the CAT5 output. The HD44C is ideal for installations requiring local switching and distribution up to 250’.

  • Page 2: Source Inputs

    DETAIL OVERVIEW [1] SOURCE LOOP-THROUGH CONNECTION The source inputs are buffered to provide an output at the same levels, assuming a 75-ohm termination is on the output. Use these connections for HD44 expansion systems. The buffers are an active circuit. The HD44 must be powered on for an active connection. [2] SOURCE INPUTS Gold-plated RCA jacks for connection from the output of the source.
  • Page 3 RING GROUND SLEEVE +12VDC, 25mA [4] IR BUS, EMITTER PORT The 3.5mm Mono jack is an emitter port. The IR signal is connected to the IR Receiver. A Xantech 283M emitter can be connected to this port. PLUG 2-Pin WECO SLEEVE The 2-Pin WECO screw terminal is an IR port.
  • Page 4 Input (Source) !{z#}SS{s#}+ Select Ping Expansion !RP+ Port Return Ping to !SP+ Xantech port 08905071B RS232 COMMAND STRUCTURE RETURN To turn on Zone 2: !2PR1+ or !02PR1+ or OK{CR} !2PR01+ or !02PR01+ ERROR{CR} To turn off Zone1: !1PR0+ or !01PR0+ or...
  • Page 5 Where: {CR#} – Carriage Return (0x0D) {z#} - Zone Number. Range is 1..4 (1..16 if expanded) {s#} - Source Input Number. Range is 1..4 {0/1} – Either 0 (zero) or 1 (one). 0 – Off, 1 – On. NAME QUERY Zone Power ?{z#}PR+ ?{z#}PR{0/1}+...

  • Page 6: Ac Power Input

    HD44C and HD44CC5 (up to 4 units), a larger High-Definition distribution system can be created. For instance, two HD44C units can be combined to create a much larger 4 source input to 8 zone output. The two HD44C units must have their own unique address (see ADDRESS (DIP SWITCH) section).
  • Page 7 [9] CAT5 ZONE OUTPUT Output connection to the HDRXSG01 receiver module. Uses standard CAT5 cable. Be sure to verify CAT5 wiring connection is correct before installation. [10] COAXIAL ZONE OUTPUT Gold-plated RCA jacks for connection to an HD monitor. Color coordinated to match all HD type products.
  • Page 8 QUICK INSTALLATION: HD44CC5 and HDRXSG01 [1] Connect the High-Definition Source to the HD44CC5 or HDTXSG01. Figure 1 below shows a HD44CC5 (video matrix transmitter) connected to the HDRXSG01 (receiver). [2] Using CAT5 cable, connect the HD44CC5 zone output or the output from the HDTXSG01 to the HDRXSG01.
  • Page 9 To change the Group Code of the additional HD44’s please see the RC68X instruction manual (section labeled CHANGING THE INTERNAL CODE GROUP NUMBER OF A XANTECH MODEL) or the Application Advisory AA-09 on the Xantech Web Site [URL: http://www.xantech.com/products/a_folder/a_aa...
  • Page 10 ADVANCE INSTALLATION FIGURE 2: Below shows a diagram for a sports bar application. With the equipment rack located near or behind the bar area, the coaxial outputs can be used for local HD monitors. The CAT5 outputs can be used to deliver HD content to areas such as outdoor patios and pool table recreational areas. FIGURE 2 FIGURE 3: The figure in the next page shows an expanded HD44CC5 system.
  • Page 11 FIGURE 3 (Note: The top unit (master unit) must be addressed as UNIT #1) 08905071B - 11 -...

  • Page 12: Common Problems And Troubleshooting

    Poor video quality (picture is washed out): Several manufacturers of cable and satellite box may have higher than normal DC offset on the video signals. When connected to an HD44C, HD44CC5, and HDTXSG01, this may result in a washed out picture. To remedy this problem, a DC blocker should be used between the source component and the HD44C, HD44CC5, and HDTXSG01.
  • Page 13 This page intentionally left blank 08905071B - 13 -...
  • Page 14 This page intentionally left blank 08905071B - 13 -...
  • Page 15 This page intentionally left blank 08905071B - 13 -...
  • Page 16 Covered product must be sent to Xantech together with proof of purchase, RA number, prepaid and insured to Xantech. Freight collect shipments will be refused. Risk of loss or damage in transit is borne by the sender.
