Specifications
Features
Performance
EDGE: E-GPRS Class 10,
GPRS: Class 12
Band, Frequency
Quad-band GSM/GPRS/EDGE
850/900/1800/1900 MHz
Packet Data
EDGE: E-GPRS Up to 240K bps,
coding scheme MCS-9, mobile station
Class B, LLC layer, 4 time slots
GPRS: Full PBCCH support, coding
scheme 1-4, mobile station Class B
Circuit-Switched
Up to 14.4K bps, non-transparent
Data
Short Message
Text & PDU, Point-to-Point (MO/MT),
Services-SMS
cell broadcast
Antenna
RF Antenna: 50 ohm SMA (female
Connector
connector)
SIM Connector
Standard 1.8 and 3V SIM receptacle
RS232 Connector
DE9
GPIO Connector
6 pin 2x3 style
Power Connector
2.5mm miniature (screw-on)
Voltage
9V to 32 VDC
Power*
Sleep
.091A, .84W @ 9V, .048A,
.96W @ 20V, .034A, 1.088W @ 32V
Typical
1.54W @ 20V; .054A, 1.73W @ 32V
Max
.416A, 3.77W @ 9V, .190A,
3.80W @ 20V, .124A, 3.97W @ 32V
Peak. 2.5A @9 V, 0.895A @ 20V,
0.625A @32V
Sleep
.098A, .91W @ 9V, .051A,
1.02W @ 20V, .035A, 1.125W @ 32V
Typical
1.60W @ 20V; .056A, 1.79W @ 32V
Max
.410A, 3.77W @ 9V, .190A,
3.80W @ 20V, .122A, 3.90W @ 32V
Peak
2.25A @9 V, 0.890A @ 20V,
0.609A @32V
Physical
4.2" W x1.1"Hx3.4"D 2 lbs
Description
12.5cmW x2.7cmH x 8.6cmD 0.2Kg
Operating
-30° to +50° C
Temperature **
UL listed @ 40°
Storage Temp
-40° to +85° C
Humidity
Relative humidity 20% to 90%
noncondensing
Certifications
EMC Compliance
FCC Part 15
EN55022
EN55024
Radio Compliance
FCC Part 22, 24
RSS132,133
EN301 489-1
EN301 489-7
EN301 511
AS/ACIF S042.1, S042.3
Safety:
Network:
*
Multi-Tech Systems, Inc recommends that the customer incorporate a 10% buffer into their power source when determining product
load.
**
UL Listed @ 40° C, limited by power supply. UL Certification does not apply or extend to an ambient above 40° C and has not been
evaluated by UL for ambient greater than 40° C.
"UL has evaluated this device for use in ordinary locations only. Installation in a vehicle or other outdoor locations has not been
evaluated by UL. UL Certification does not apply or extend to use in vehicles or outdoor applications or in ambient above 40° C."
Multi-Tech Systems, Inc. MultiModem iCell User Guide
MTCMR-E1
.149A,.1.37W @ 9V, .077A,
MTCMR-E1-GP
.160A,.1.48W @ 9V, .080A,
UL60950-1
cUL60950-1
IEC60950-1
PTCRB
MTCMR-C1
CDMA2000 1xRTT
Dual-band 800/1900 MHz CDMA; 800
MHz and 800/1900 MHz with R-UIM
support
Up to 153.6K bps forward and reverse
IS-95A, IS 95B up to 14.4K bps forward
and reverse
Text & PDU, Point-to-Point (MO/MT),
cell broadcast
RF Antenna: 50 ohm SMA (female
connector)
-
DE9
6 pin 2x3 style
2.5mm miniature(screw-on)
9V to 32 VDC
Sleep
.048A, .44W @ 9V, .027A, .54W
@ 20V, .021A, .67W @ 32V
Typical
.128A,.1.18W @ 9V, .065A,
1.30W @ 20V; .046A, 1.47W @ 32V
Max
.360A, 3.31W @ 9V, .171A, 3.42W
@ 20V, .115A, 3.68W @ 32V
MTCMR-C1-GP
Sleep
.096A, .89W @ 9V, .052A, 1.04W
@ 20V, .037A, 1.18 W @ 32V
Typical
.175A,.1.62W @ 9V, .092A,
1.84W @ 20V; .062A, 1.98W @ 32V
Max
.435A, 4.00W @ 9V, .205A, 4.10W
@ 20V, .135A, 4.32W @ 32V
4.2" W x1.1"Hx3.4"D 2 lbs
12.5cmW x2.7cmH x 8.6cmD 0.2Kg
-30° to +50° C
UL listed @ 40°
-40° to +85° C
Relative humidity 20% to 90%
noncondensing
EMC Compliance
FCC Part 15
Radio Compliance
FCC Part 22, 24
RSS132,133
Safety:
UL60950-1
cUL60950-1
IEC60950-1
Network:
CDG 1&2
Chapter 1
MTCMR-G2
GPRS Class 10
Quad-band GSM
850/900/1800/1900 MHz
Up to 85.6K bps, coding schemes CS1
to CS4
Up to 14.4K bps transparent and non-
transparent
Text & PDU, Point-to-Point, cell
broadcast
RF Antenna: 50 ohm SMA (female
connector)
Standard 1.8 and 3V SIM receptacle
DE9
6 pin 2x3 style
2.5mm miniature (screw-on)
9V to 32 VDC
Sleep
.069A, .64W @ 9V, .038A, .76W
@ 20V, .030A, .96W @ 32V
Typical
.109A,.1.01W @ 9V, .056A,
1.12W @ 20V; .041A, 1.3W @ 32V
Max
.194A, 1.79W @ 9V, .096A,
1.92W @ 20V, .065A, 2.1W @ 32V
Peak. 1.53A @9 V, 0.668A @ 20V,
0.453A @32V
MTCMR-G2-GP
Sleep
.083A, .77W @ 9V, .046A, .92W
@ 20V, .036A, 1.15W @ 32V
Typical
.130A,.1.19W @ 9V, .067A,
1.34W @ 20V; .050A, 1.6W @ 32V
Max
.233A, 2.13W @ 9V, .115A,
2.30W @ 20V, .078A, 2.5W @ 32V
Peak. 1.83A @9 V, 0.801A @ 20V,
0.543A @32V
4.2" W x1.1"Hx3.4"D 2 lbs
12.5cmW x2.7cmH x 8.6cmD 0.2Kg
-30° to +50° C
UL listed @ 40°
-40° to +85° C
Relative humidity 20% to 90%
noncondensing
EMC Compliance
FCC Part 15
EN55022
EN55024
Radio Compliance
FCC Part 22, 24
RSS132,133
EN301 489-1
EN301 489-7
EN301 511
AS/ACIF S042.1, S042.3
Safety:
UL60950-1
cUL60950-1
IEC60950-1
Network:
PTCRB
