Chapter 1 – Product Description and

Product Description

The Multi-Tech MultiModem® iCell is a mid-range wireless modem containing an embedded TCP/IP protocol stack for Internet
connectivity, serial and USB connectors for modem configuration, and a General Purpose Input/Output (GPIO) connector for
customer interface connection. All MultiModem iCells can be desktop or panel mounted.
Model
MTCMR-E1
MTCMR-E1-GP
MTCMR-C1
MTCMR-C1-GP
MTCMR-G2
MTCMR-G2-GP
The MTCMR contains an embedded TCP/IP protocol stack to bring Internet connectivity to any device without making changes
to its hardware design. Using the Internet protocols and the wireless connection to an IP network, the modem sends and
receives data over the Internet. The modem offers short message service (SMS) features such as text and PDU, Point-to-point
(MT/MO) and cell broadcast.
The MultiModem iCell modem delivers some of the fastest cellular wireless data speeds using the various Internet protocols.
This is ideal for highly data-intensive applications such as remote video surveillance and other multimedia applications where
you are sending digital images, web pages and photographs.
The MultiModem iCell modem is designed around a wide variety of interface options including serial RS-232, USB, and General
Purpose Input/Output (GPIO). The serial RS-232 and USB connections provide seamless connectivity for configuration of your
application. The GPIO interface provides five user-configurable GPIO's as CMOS input or output ports to be connected to a
customer's peripheral device. A customer application in which the GPIO interface could be used is one with a monitoring device
connected to the GPIO interface in which the monitoring device triggers an event in the IP stack to establish a TCP or UDP
socket connection or send an email stating that the monitoring device was triggered by high water.
Multi-Tech Systems, Inc. MultiModem iCell User Guide
Specifications
Quad-band E-GPRS Class 10 performance
Quad-band E-GPRS Class 10 performance; GPS functionality
Multi-band CDMA2000 1xRTT performance
Multi-band CDMA2000 1xRTT performance; GPS functionality
Quad-band GSM/GPRS Class 10 performance
Quad-band GSM/GPRS Class 10 performance; GPS functionality
Description
