Operating Manual
PA27224A01
UPS003LSM
Rev: 02 3-2014
UNINTERRUPTIBLE POWER SUPPLY LOAD SENSE MODULE
OPERATION MANUAL
Original Instructions
© Panduit Corp. 2014
TO REDUCE THE RISK OF INJURY, USER
MUST READ INSTRUCTION MANUAL
Email:
Technical Support:
techsupport@panduit.com
Tel: 1-888-506-5400, ext. 83255
EU Website:
www.panduit.com/emea
Panduit Europe • EMEA Service Center
www.panduit.com
EU Email:
Almelo, Netherlands
emeatoolservicecenter
Tel: +31-546-580-452 • Fax: +31-546-580-441
@panduit.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panduit UPS003LSM
Summary of Contents for Panduit UPS003LSM
- Page 1 TO REDUCE THE RISK OF INJURY, USER MUST READ INSTRUCTION MANUAL Email: Technical Support: techsupport@panduit.com Tel: 1-888-506-5400, ext. 83255 EU Website: www.panduit.com/emea Panduit Europe • EMEA Service Center www.panduit.com EU Email: Almelo, Netherlands emeatoolservicecenter Tel: +31-546-580-452 • Fax: +31-546-580-441 @panduit.com...
-
Page 2: Table Of Contents
OPERATION MANUAL UPS003LSM © Panduit Corp. 2014 TABLE OF CONTENTS UPS LSM GENERAL SPECIFICATIONS ................2 Model Number ................2 Input Power ..................2 Output Power ................. 2 Environmental ................2 Compliance ..................2 Installation ..................2 Performance .................. 3 PRECAUTIONS AND GENERAL GUIDELINES.............. -
Page 3: Ups Lsm General Specifications
OPERATION MANUAL UPS003LSM © Panduit Corp. 2014 UPS LSM GENERAL SPECIFICATIONS Model Number UPS003LSM Input Power Voltage: 30.0 VDC MAX Current: 5 A MAX Output Power Voltage: 30.0 VDC MAX Sense: 100 mV MAX Current: 5 A MAX Environmental Operating Temperature: -40 to +60°C. -
Page 4: Performance
• Save all warnings and instructions for future reference. Panduit Corp. recommends the UPS LSM be used with all installed safety features. Customer assumes all liability for injury that could result from improper use of this UPS LSM and responsibility for all necessary training to ensure safe operation of this UPS LSM. -
Page 5: Electrical Safety Practices
OPERATION MANUAL UPS003LSM © Panduit Corp. 2014 Electrical Safety Practices GROUNDING: In the event of a malfunction or breakdown, grounding provides a path of least resistance for electric current which reduces the risk of electrical shock. Improper connection of the equipment grounding conductor can result in a risk of electric shock. -
Page 6: Service
The UPS003LSM is designed for redundant power back-up systems. The UPS003LSM is intended to function only with the Panduit UPS003024024015 (UPS) unit. The UPS is rated for a 24 VDC maximum output rating. The UPS LSM is connected to the main power supply line of 24 VDC. -
Page 7: Installation
OPERATION MANUAL UPS003LSM © Panduit Corp. 2014 1.4. INSTALLATION Figure 1: DIN Rail Installation No minimum spacing to other modules is required for proper operation of the device. To install the UPS LSM, place the module with the DIN rail guideway on the top edge of the DIN rail and then snap it downwards and shown in Figure 1. -
Page 8: Figure 3: Load Sense Module
OPERATION MANUAL UPS003LSM © Panduit Corp. 2014 Figure 3: Load Sense Module Pins 3 and 4 of the load sense module are connected to the sense input terminals of the UPS. Note that pin 3 of the current sense resistor must be connected to the “+” sense terminal and pin 4 of the current sense resistor must be connected to the “-“sense terminal.
