Quantum Evolution installation and user manual
REMOTE CONTROL (Not included with 4 Chn Non DVD units)
1. Power: Power ON/OFF
2. Rec: Start & Stop Recording
3.ⓞ ~⑨ : Key for figure and character
4. P/T/Z: Entering PTZ menu directly
5. OSD: Operating OSD ON/OFF
6. SEQ: Key for SEQ operation
7. LOG: Direct access Log list
8. INFO: Direct access system Info.
9. ID: Reserved.
10. MUTE: Audio Mute
11. AUDIO: Available audio switching
when user select this key
12. MENU: Entering system menu
13. SEARCH: Entering search
14. ARROW & SPLIT: Key moving left,
right, up and down. Also, Screen split
display shows
15. VOL"+,-" : Up, down volume
16. CH "+,-" : Up, down channel(s)
17. ( ) : Play(or fast forward)
18. ◀ (◀ ) : Reverse play
19 II : Pause
20. █: Stopping playback
21. Cam: Changing PTZ icon
22. P/T: Pan &Tilt
23. Z/F: Zoom/ & Focus
24. DIS: Channel Division
21~24:doesn‟t work with Quantum Evo.
