Power Switch - Invacare Platinum IRC5LXO2 Operator's Manual

Oxygen
Tubing
Humidifier Outlet
FIGURE 5.4
For optimum performance, Invacare recommends that
each concentrator be on and running for a minimum of 30
minutes at a time. Shorter periods of operation may
reduce maximum product life.

Power Switch

NOTE: For this procedure, refer to FIGURE 5.5 on page 23.
1. Press power switch to on position. All the panel lights and
the audible alarm will come on for one second, indicating
that the unit is functioning properly. After one second,
only the GREEN system ok/power light will stay on.
Part No 1145728
SECTION 5 —OPERATING INSTRUCTIONS
Attaching the Oxygen Tubing
WARNING
FIGURE 5.5
23
On/Off (I/O)
Power Switch
Power Switch
Oxygen Outlet
Connector
Platinum™Series
