OPERATION / MAINTENANCE

POWER SWITCH

1. Press power switch to the
located on the control panel, will illuminate a
alarm will "beep" three (3) times indicating that the system is
functioning properly.

FLOWRATE

1. Turn the flowrate knob to the setting prescribed by your physician
or therapist.
NOTE: To properly read the flowmeter, locate the prescribed flowrate line on
the flowmeter. Next, turn the flow knob to until the ball rises to the line. Now,
center the ball on the L/min. line prescribed.
FIGURE 5 - ADJUSTING THE FLOWRATE
SENSO ® OXYGEN PURITY INDICATOR-IF YOUR
2
UNIT FEATURES THE O2 SENSOR FEATURE
This feature monitors the purity of oxygen generated by the oxygen
concentrator. If purity falls below factory preset standards, indicator
lights on the control panel will illuminate.
position. The power light (I/O),
WARNING
Flow knob
Ball
16
light. The
