General Troubleshooting Tips
Table D-2
Summary
Moving a network connection
from the phone to a workstation
Changing the phone
configuration
Dual-Tone Multi-Frequency
(DTMF) delay
Codec mismatch between the
phone and another device
Sound sample mismatch
between the phone and another
device
Gaps in voice calls
Loopback condition
Cisco ATA 190 Analog Telephone Adaptor Administration Guide for SIP (Version 1.0)
D-8
ATA 190 Troubleshooting (continued)
Explanation
If you are powering your phone through the network connection,
you must be careful if you decide to unplug the phone's network
connection and plug the cable into a desktop computer.
Caution
By default, the network configuration options are locked to prevent
users from making changes that could impact their network
connectivity. You must unlock the network configuration options
before you can configure them.
When you are on a call that requires keypad input, if you press the
keys too quickly, some of them might not be recognized.
The RxType and the TxType statistics show the codec that is being
used for a conversation between this ATA 190 and the other device.
The values of these statistics should match. If they do not, verify
that the other device can handle the codec conversation or that a
transcoder is in place to handle the service.
The RxSize and the TxSize statistics show the size of the voice
packets that are being used in a conversation between this ATA 190
and the other device. The values of these statistics should match.
Check the AvgJtr and the MaxJtr statistics. A large variance
between these statistics might indicate a problem with jitter on the
network or periodic high rates of network activity.
A loopback condition can occur when the following conditions are
met:
The SW Port Configuration option in the Network
•
Configuration menu on the phone is set to 10 Half
(10-BaseT/half duplex)
• The phone receives power from an external power supply
The phone is powered down (the power supply is disconnected)
•
In this case, the switch port on the phone can become disabled and
the following message will appear in the switch console log:
HALF_DUX_COLLISION_EXCEED_THRESHOLD
To resolve this problem, re-enable the port from the switch.
Chapter D
The computer's network card cannot receive power
through the network connection; if power comes through
the connection, the network card can be destroyed. To
protect a network card, wait 10 seconds or longer after
unplugging the cable from the phone before plugging it
into a computer. This delay gives the switch enough time
to recognize that there is no longer a phone on the line
and to stop providing power to the cable.
Troubleshooting and Maintenance
