- Page 1 Business Networking Solution Installation Guide Gigabit Uplink Unmanaged Switch TL-SL1226/TL-SL1351...
-
Page 2: Fcc Statement
Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. - Page 3 Network Administrator Conventions Due to the similarity in structure of TL-SL1226/TL-SL1351 Gigabit Uplink Unmanaged Switch series, in this Installation Guide we take TL-SL1351 as an example to illustrate Chapter 2 Installation, Chapter 3 Lightning Protection and Chapter 4 Connection. This Guide uses the specific formats to highlight special messages. The following table lists the notice icons that are used throughout this guide.
-
Page 4: Table Of Contents
Contents Introduction ——————————— 01 Chapter 1 Product Overview ..............01 Features ..................01 Appearence ................02 Installation ———————————— 04 Chapter 2 Package Contents ..............04 Safety Precautions ..............04 Installation Tools..............06 Product Installation ..............07 Lightning Protection ———————— 09 Chapter 3 Cabling Reasonably..............09 Connect to Ground..............11 equipotential Bonding ............12 Use Lightning Arrester ............13 Connection ———————————... -
Page 5: Introduction
ChaCter C Introduction Product Overview TL-SL1226/TL-SL1351 Gigabit Uplink Unmanaged Switch provides you with a high- performance, low-cost, easy-to-use, seamless and standard upgrade to boost your old network to 1000Mbps. Increase the speed of your network server and backbone connections, making Gigabit connection to a server or uplinking a network necessarily. -
Page 6: Appearence
The front panel of TL-SL1226 is shown as the following figure. LEDs 10/100Mbps RJ45 Port 10/100/1000Mbps RJ45 Port Figure 1-1 Front Panel of TL-SL1226 The front panel of TL-SL1351 is shown as the following figure. LEDs 10/100Mbps RJ45 Port 10/100/1000Mbps RJ45 Port SFP Port Figure 1-2... -
Page 7: Rear Panel
Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or 1000Mbps. Each has a corresponding 1000Mbps LED. SFP Port (for TL-SL1351 Only) Designed to install the SFP module. TL-SL1351 features one individual SFP port. Rear Panel ■... -
Page 8: Installation
Gigabit Uplink Unmanaged Switch ChaCter 1 Installation Package Contents Make sure that the package contains the following items. If any of the listed items is damaged or missing, please contact your distributor. One Switch This Installation Guide One Power Cord Two mounting brackets and the fittings 111 Safety Precautions... -
Page 9: Site Requirements
Gigabit Uplink Unmanaged Switch Site Requirements ■ To ensure normal operation and long service life of the device, please install it in an environment that meets the requirements described in the following subsection. Temperature/Humidity Please keep a proper temperature and humidity in the equipment room. Too high/low humidity may lead to bad insulation, electricity leakage, mechanical property changes and corrosions. -
Page 10: Installation Tools
Gigabit Uplink Unmanaged Switch Lightening Protection Extremely high voltage currents can be produced instantly when lightning occurs and the air in the electric discharge path can be instantly heated up to 20,000℃. As this instant current is strong enough to damage electronic devices, more effective lightning protection measures should be taken. -
Page 11: Product Installation
Gigabit Uplink Unmanaged Switch 114 Product Installation Desktop Installation ■ To install the device on the desktop, please follow the steps: Set the device on a flat surface strong enough to support the entire weight of the device with all fittings. Remove the adhesive backing papers from the rubber feet. - Page 12 Gigabit Uplink Unmanaged Switch Rack Figure 2-3 Rack Installation Caution: Please set 5~10cm gaps around the device for air circulation. ■ Please avoid any heavy thing placed on the device. ■ Please mount devices in sequence from the bottom to top of the rack and ensure a ■...
-
Page 13: Chapter 3 Lightning Protection
Gigabit Uplink Unmanaged Switch ChaCter 1 Lightning Protection Cabling Reasonably In the actual network environment, you may need cable outdoors and indoors, and the requirements for cabling outdoors and indoors are different. A reasonable cabling system can decrease the damage of induced lightning to devices. Note: It's not recommended using Ethernet cables outdoors. -
Page 14: Requirements For Cabling Indoors
Gigabit Uplink Unmanaged Switch Requirements for Cabling Indoors ■ When cabling indoors, keep a certain distance away from the devices that may cause high-frequency interferences, such as down-conductor cable, powerline, power transformer and electromotor. The main cable should be paved in the metal raceway of the access shaft. When ■... -
Page 15: Connect To Ground
Gigabit Uplink Unmanaged Switch Device Min Distance (m1 Switch case 1.00 Transformer room 2.00 Elevator tower 2.00 Air-conditioner room 2.00 111 Connect to Ground Connecting the device to ground is to quickly release the lightning over-voltage and over-current of the device, which is also a necessary measure to protect the body from electric shock. -
Page 16: Equipotential Bonding
Gigabit Uplink Unmanaged Switch Connecting to the Ground via the Power Supply ■ If the device is installed in the normal environment, the device can be grounded via the PE (Protecting Earth1 cable of the AC power supply as shown in the following figure. Figure 3-2 Connecting to the Ground Note: The figure is to illustrate the application and principle. -
Page 17: Use Lightning Arrester
Gigabit Uplink Unmanaged Switch Grounding Terminal Equipotential Bonding Cable Ground Cable Grounding Bar Figure 3-3 Equipotential Bonding When equipotential bonding, please note that the cable should be copper wrapped Kelly with its area being 6mm at least. The shorter cable the better, and use a grounding bar to establish an equipotential bonding point. - Page 18 Gigabit Uplink Unmanaged Switch Signal lightning arrester is used to protect RJ45 ports of the device from lightning. When cabling outdoors, please install a signal lightning arrester before connecting the cable to the device. When purchasing or using a signal lightning arrester, please observe the following rules: The port rate of the signal lightning arrester should match the rate of the desired ■...
-
Page 19: Connection
Figure 4-1 Connecting the RJ45 Port 411 SFP Port Connect the SFP port to a SFP module. The switch could identify and configure the SFP module automatically (for TL-SL1351 only1. SFP Port SFP Module Figure 4-2 Inserting the SFP Module... -
Page 20: Power On
LED indicators will light up for three seconds and then go off. This process indicates that the device is successfully initialized. For TL-SL1351, the PWR LED indicator will light up first and remain ON. Other LED ■... -
Page 21: Appendix A Hardware Specifications
Item Content IEEE802.3 10Base-T IEEE802.3u 100Base-TX IEEE802.3ab 1000Base-T Standards IEEE802.3z 1000Base-X (for TL-SL1351 only1 ANSI/IEEE Std 802.3 Nway IEEE802.3x 10Base-T: UTP/STP of Cat. 3 or above(maximum 100m1 100Base-TX: UTP/STP of Cat. 5 or above(maximum 100m1 Transmission Medium 1000Base-TX: UTP/STP of Cat. 5 or above(maximum 100m1 Safety &... -
Page 22: Appendix B Technical Support
For all other technical support, please contact us by using the following details: ■ Global Tel: +86 755 2650 4400 Fee: Depending on rate of different carriers, IDD. E-mail: support@tp-link.com Service time: 24hrs, 7 days a week Singapore Tel: +65 6284 0493 Fee: Depending on rate of different carriers. - Page 23 Australia/New Zealand Tel: NZ 0800 87 5465 (Toll Free1 AU 1300 87 5465 (Depending on 1300 policy.1 E-mail: support.au@tp-link.com (Australia1 support.nz@tp-link.com (New Zealand1 Service time: 24hrs, 7 days a week Switzerland Tel: +41 (01 848 800 998 (German Service1 Fee: 4-8 Rp/min, depending on rate of different time.
- Page 24 Website: http://www.tp-link.com E-mail: support@tp-link.com 7106504623 Rev4.0.1...
