setup

This section provides an overview of how to connect and configure the DP DA2.
1.
2.
3.
4.
5.
6.
7.
8.
9.
Place the DP DA2 in a suitable location.
If necessary, connect the DP DA2 to a control PC using either the
captive screw connector
(see page 9).
Power on the DP DA2 (see page 4) and the PC and configure the DP DA2 as
required, using SIS commands
Connect up to two display devices
page 5). To record EDID (see page 6), the display with the lowest resolution should
be connected to output 1.
NOTES:
Both display devices must have resolution equal to or higher than the EDID
•
values being used.
• Extron recommends that the displays connected to outputs 1 and 2 are the
same model or have the same native resolution.
Power on the display devices.
If necessary,
record the EDID
Select the correct
settings for DIP switches
Connect the source device to the
Power on the source device.
(see page 8) or the front panel USB mini B connector
(see page 15).
to the rear panel output connectors (see
from the device connected to output 1 (see page 6).
1 and 2 (see page 7).
rear panel input connector
rear panel RS-232
(see page 5).
DP DA2 • Setup 12
