MLC 104 IP Plus Series • Setup Guide (Continued)
Mounting
Attach cables using the preceding pages
as a guide, then securely mount the
MLC and other devices into the wall
or furniture. Optional mounting kits
(see part numbers at right) are
available for use with the MLC. Read
the instructions and UL guidelines
that come with the any mounting kit
for installation procedures.

Setup Checklist: How to Proceed With Installation

Get Ready
… …
Familiarize yourself with the features of the MLC 104 IP Plus.
… …
Download and install the latest version of the Extron Global Configurator (GC) software and the latest driver
package (avail able from
… …
Obtain IP setting information for the MLC from the network administrator.
… …
Obtain model names and setup information for devices the MLC will control.
Perform Physical Installation
… …
Mount the unit.
… …
Cable devices to ports on the MLC.
… …
Connect power cords and turn on the devices in the following order: output devices (projectors, monitors,
speakers), the MLC, a PC (for setup), SCP panel (if desired), then all input devices (such as DVD players).
Configure the MLC
… …
Connect the PC and the MLC to the same Ethernet subnetwork and use ARP via Telnet, Extron DataViewer, or a
similar application to configure the MLC for network communication.
… …
Create a new GC project and configure the MLC. See the Global Configurator Help file.
… …
Test the system.
If you have questions during installation and setup, you can call the
Extron S3 Control Systems Support
Extron Headquarters
+800.633.9876 Inside USA/Canada Only
Extron USA - West Extron USA - East
+1.714.491.1500 +1.919.863.1794
+1.714.491.1517 FAX +1.919.863.1797 FAX
© 2011 Extron Electronics All rights reserved. All trademarks mentioned are the property of their respective owners.
6
Optional mounting kits
SMB 102 Two-gang Surface Mount Box (black)
SMB 104 Four-gang Surface Mount Box (black)
MLM 104 6GWP Six-Gang Wall Mounting Kit (black)
MLM 104 L Replacement Lectern Mounting Kit (black, white)
MLM 104 LAAP Replacement Lectern Mounting Kit with AAP
opening (black )
www.extron.com or on the Extron Software Products Disc.)
Hotline.
Extron Europe Extron Asia
+800.3987.6673 +800.7339.8766
Inside Europe Only Inside Asia Only
+31.33.453.4040 +65.6383.4400
+31.33.453.4050 FAX +65.6383.4664 FAX
Extron S3 Sales & Technical Support Hotline
Extron Japan Extron China
+4000.EXTRON
+4000.398766
+81.3.3511.7655
Inside China Only
+81.3.3511.7656 FAX
+86.21.3760.1568+86.
21.3760.1566 FAX
Part number
70-357-02, -03
Extron Middle Extron Korea
East
+82.2.3444.1571
+971.4.2991800 +82.2.3444.1575 FAX
+971.4.2991880 FAX
www.extron.com
60-640-02
60-642-02
70-355-02
70-358-02
or the
Extron India
1800.3070.3777
Inside India Only
+91-80-3055.3777
+91 80 3055 3737 FAX
68-1289-01 Rev. E
