User’s Manual Do not connect this device to a computer data or CAUTION telecommunications network TP Transmitters and Receivers HIgh Resolution Video, Composite Video, and Stereo Audio Extron Electronics, USA Extron Electronics, Europe Extron Electronics, Asia Extron Electronics, Japan Twisted Pair Cable Transmission Products 1230 South Lewis Street Beeldschermweg 6C 135 Joo Seng Road, #04-01...
Page 2
Precautions Safety Instructions • English Extron’s Warranty Warning This symbol is intended to alert the user of important Power sources • This equipment should be operated only from the power source indicated on the product. This equipment is intended to be used with a main operating and maintenance (servicing) instructions Extron Electronics warrants this product against defects in materials and power system with a grounded (neutral) conductor.
Page 3
TIA/EIA T 568A or TIA/EIA T 568B wiring standards. You can use either standard, but use the same standard on both ends of the cable. See the figure on the next page for wiring. IN1124/28/30 Transmission System • Quick Start Guide...
68-754-01 Rev. A Printed in the USA 12 02 All trademarks mentioned in this manual are the properties of their respective owners. IN1124/28/30 Transmission System • Quick Start Guide IN1124/28/30 Transmission System • Table of Contents...
Table of Contents, cont’d IN1124/IN1128/IN1130 Transmission System Chapter One Introduction Introduction Features IN1124/28/30 Transmission System • Table of Contents...
This manual documents the installation, features, and operation 100 meters of skew (see Termination of TP cable in of the Extron IN1124 and IN1128 TP twisted pair (TP) chapter 2). We also recommend the use of pre- transmitters/distribution amplifiers (referred to in this manual terminated and tested cables.
(right) of two 3.5 mm stereo mini jacks. RJ-45 connectors — Allows connection to up to four Extron IN1130 TP RGB video receivers. RJ-45 connector — Allows attachment to an Extron IN1124 or IN1128 TP transmitter/DA. Mounting — Can be rack mounted with Extron’s 1U rack shelf (part #IN9080).
Introduction, cont’d IN1124/IN1128/IN1130 Transmission System Chapter Two Installation and Operation Installation Overview Rack Mounting the Transmitter Furniture Mounting the Receiver Transmitter Cabling Transmitted Signal Cabling Receiver Cabling Operation Troubleshooting IN1124/28/30 Transmission System • Introduction...
Page 9
Connect the input to the transmitter. See Transmitter cabling in this chapter. Connect the local monitor to the transmitter. See Figure 2-1 — Rack mounting the IN1124 Transmitter cabling in this chapter. Install an optional IN9088B blank panel or another unit to Connect the cables between the transmitter and the TP the rack shelf.
Figure 2-2 — Under-desk or through-desk mounting Figure 2-3 — Installation features, IN1124 Transmitter Cabling The IN1124 (figure 2-3) and the IN1128 (figure 2-4) accept and transmit computer video and PC audio. These transmitters can also accommodate component video, S-video, or composite...
White-orange White-green Green/H. sync+ Transmitted Signal Cabling Blue Blue Blue+ The IN1124 (figure 2-3) and IN1128 (figure 2-4) transmit White-blue White-blue Blue- 2 3 4 5 6 7 8 computer video and PC audio. The IN1130 (figure 2-6) receives Orange Green Green/H.
3.5 mm jacks to local powered speakers. through a process of trial and error, equalize any pair skew with coax extensions on the red, green, and/or blue outputs. IN1124/28/30 Transmission System • Installation and Operation IN1124/28/30 Transmission System • Installation and Operation...
The transmission distance may be too long. Try shortening the distance between the transmitter and receivers. Specifications Call the Extron S Sales & Technical Support Hotline if Included Parts necessary. Accessories Installation Kits Cables/Adapters 2-10 IN1124/28/30 Transmission System • Installation and Operation...
Audio input IN1130 ....... 1 shielded female RJ-45 Number/signal type Nominal level ....... 0.7V p-p for RGB IN1124, IN1128 ....1 stereo, unbalanced, and 1 local output Minimum/maximum levels ..Analog: 0.3V to 1.5V p-p with no offset at IN1130 ....... 1 set of proprietary analog signals...
Twisted pair transmitter/DA for high-resolution Enclosure dimensions video and audio IN1128-2 IN1124, IN1128 ....1.7” H x 8.5” W x 6.0” D (1U high, half IN1124/28/30 Transmission System User’s Guide rack width) 9.0VDC, 120VAC 60Hz, 2.0A external power supply IN9211-1 4.2 cm H x 21.6 cm W x 14.7 cm D...
