Advanced Instructions – Reserved for Windows program
IR Block
Read (Upload)
Write (Download)
Flag Block
Read (Upload)
Write (Download)
Unit Reset
Reset Unit
Flag Block: Consists of fifteen bytes (0-14) that will used for handling special functions for current and future operation.
Byte 0 – Power on delay
Byte 1 – Power off delay
Byte 2 – Triple action switching delay (.5 second * value)
Byte 3 – Relay control
Byte 4 – n/u
Byte 5 – n/u
Byte 6 – n/u
Byte 7 – Mute control & misc. flags
(msb)
(lsb)
Byte 8 – Video type (composite video or S-video)
Byte 14 - Checksum
A-3
ASCII Hex
n/a 80 83
n/a 80 82 [8k bytes]
ASCII Hex
n/a 80 85
n/a [Byte0]*[Byte1]91
n/a [Byte2]*[Byte3]93
n/a [Byte6]*[Byte7]97
n/a [Byte8]* 30 99
ASCII Hex
n/a 80 81
Bit 7 - True = Mute audio upon display-power down.
Bit 6 - True = Limit System volume upon switcher power up.
Bit 5 - True = Send responses to RS-232 commands.
Bit 4 - True = Send channel IR command upon display-power up.
Bit 3 - True = Enable front panel volume
Bit 2 - reserved
Bit 1 - reserved
Bit 0 - reserved
Note: Factory default = all bits on (hex FF).
Unit response
8k bytes of data
Dnl
¿
Unit response
15 bytes of data
Dnl
¿
Dnl
¿
Dnl
¿
Dnl
¿
Unit response
Upd
¿
