Extron electronics SYSTEM 5 IP Manual

The Switcher
Projector
ON/OFF

Using the projector

1. Press the "ON" button on the Switcher.
2. Press the "INPUT SELECTION" button that corresponds with the
video device (VCR/DVD, Computer, or laptop) that you want to
use.
3. When you are finished press the "OFF" button on the Switcher.

Connecting your laptop

1. Turn on the projector.
2. Plug the VGA cable (located in one of the drawers) into the
Switcher as shown above.
3. Press the button labeled "LAPTOP" on the Switcher.
4. If an internet connection is required plug the network cable into
the jack labeled "NETWORK" and the other end into your
laptop's network port OR use the wireless network.
The Audio Panel
Audio System
ON/OFF

Using the audio system

1. Press the GREEN "ON" button on the audio panel.
2. Adjust the volume using the volume knob.
3. When you are finished press the RED "OFF" button to turn the
audio system off.
Note: The wireless microphone will be in the one of the drawers
in the cabinet. Make sure to check both drawers. Not all rooms
are equipped with a wireless microphone.
Select Input
Connect audio
Audio
device here.
Volume
Connect
Laptop Here
VGA Cable
Network/Internet
connection for
laptop
