LANCOM OAP-382
Routing functions
DHCPv6
Layer 2 functions
ARP lookup
LLDP
LAN protocols
IP
Rapid Spanning Tree
IPv6
IPv6
Dual Stack
IPv6 compatible LCOS applications
WAN protocols
Ethernet
IPv6
Tunneling protocols (IPv4/IPv6)
WAN operating mode
xDSL (ext. modem)
Interfaces
Ethernet port
SFP Slot
External antenna connectors
LCMS (LANCOM Management System)
LANconfig
LANmonitor
WLANmonitor
Firewall GUI
Automatic software update
DHCPv6 client, DHCPv6 server, DHCPv6 relay, stateless- and stateful mode, IPv6 address (IA_NA), prefix delegation (IA_PD), DHCPv6 reconfigure
(server and client)
Packets sent in response to LCOS service requests (e.g. for Telnet, SSH, SNTP, SMTP, HTTP(S), SNMP, etc.) via Ethernet can be routed directly to the
requesting station (default) or to a target determined by ARP lookup
Automatic discovery of network topology in layer 2 networks (Link Layer Discover Protocol).
ARP, proxy ARP, BOOTP, DHCP, DNS, HTTP, HTTPS, IP, ICMP, NTP/SNTP, NetBIOS, PPPoE (server), RADIUS, RIP-1, RIP-2, RTP, SIP, SNMP, TCP, TFTP,
UDP, VRRP, VLAN
802.1d Spanning Tree and 802.1w Rapid Spanning Tree support for dynamic path selection with redundant layer 2 connections
NDP, stateless address autoconfiguration (SLAAC), stateful address autoconfiguration (with DHCPv6), router advertisements, ICMPv6, DHCPv6,
DNS, HTTP, HTTPS, PPPoE, TCP, UDP
IPv4/IPv6 dual stack
WEBconfig, HTTP, HTTPS, SSH, Telnet, DNS, TFTP, Firewall
PPPoE, Multi-PPPoE, ML-PPP, PPTP (PAC or PNS) and IPoE (with or without DHCP), RIP-1, RIP-2, VLAN, IP
IPv6 over PPP (IPv6 and IPv4/IPv6 dual stack session), IPoE (autoconfiguration, DHCPv6 or static)
6to4, 6in4, 6rd (static and via DHCP)
ADSL1, ADSL2 or ADSL2+ with external ADSL2+ modem
1 Gigabit Ethernet Port, 10/100/1000 Mbit/s, High Power PoE (56V) with supplied PoE Injector only
Harting SFP Slot (HAN 3A SFP) for pluggable SFP module, copper SFP modules are not supported, SFP module and fiber cable not included in
delivery
Four N connectors for external LANCOM AirLancer Extender antennas or for antennas from other vendors. Please respect the restrictions which
apply in your country when setting up an antenna system. For information about calculating the correct antenna setup, please refer to
www.lancom-systems.com
Configuration program for Microsoft Windows, incl. convenient Setup Wizards. Optional group configuration, simultaneous remote configuration
and management of multiple devices over IP connection (HTTPS, HTTP, TFTP). A tree view of the setting pages like in WEBconfig provides quick
access to all settings in the configuration window. Password fields which optionally display the password in plain text and can generate complex
passwords. Configuration program properties per project or user. Automatic storage of the current configuration before firmware updates. Exchange
of configuration files between similar devices, e.g. for migrating existing configurations to new LANCOM products. Detection and display of the
LANCOM managed switches. Extensive application help for LANconfig and parameter help for device configuration. LANCOM QuickFinder as search
filter within LANconfig and device configurations that reduces the view to devices with matching properties
Monitoring application for Microsoft Windows for (remote) surveillance and logging of the status of LANCOM devices and connections, incl. PING
diagnosis and TRACE with filters and save to file. Search function within TRACE tasks. Wizards for standard diagnostics. Export of diagnostic files
for support purposes (including bootlog, sysinfo and device configuration without passwords). Graphic display of key values (marked with an icon
in LANmonitor view) over time as well as table for minimum, maximum and average in a separate window, e. g. for Rx, Tx, CPU load, free memory.
Monitoring of the LANCOM managed switches. Flick easily through different search results by LANCOM QuickFinder
Monitoring application for Microsoft Windows for the visualization and monitoring of LANCOM WLAN installations, incl. Rogue AP and Rogue
Client visualization. LANCOM QuickFinder as search filter that reduces the view to devices with matching properties
Graphical user interface for configuring the object-oriented firewall in LANconfig: Tabular presentation with symbols for rapid understanding of
objects, choice of symbols for objects, objects for actions/Quality of Service/remote sites/services, default objects for common scenarios, individual
object definition (e.g. for user groups)
Voluntary automatic updates for LCMS. Search online for LCOS updates for devices managed by LANconfig on the myLANCOM download server
(myLANCOM account mandatory). Updates can be applied directly after the download or at a later time
Features as of: LCOS 8.82
