LANCOM OAP-382
WLAN
Frequency band 2.4 GHz and 5 GHz
Data rates 802.11b/g
Data rates 802.11a/ h
Range (outdoor / P2P)
Output power at radio module, 2.4 GHz
Output power at radio module, 5 GHz
Output power at radio module, 2.4 GHz
(WLAN-2)
Output power at radio module, 5 GHz
(WLAN-2)
Max. radiated power (EIRP), 2.4 GHz band
Max. radiated power (EIRP), 5 GHz band
Minimum transmission power
Receiver sensitivity 2.4 GHz
Receiver sensitivity 5 GHz
Receiver sensitivity 2.4 GHz (WLAN-2)
Receiver sensitivity 5 GHz (WLAN-2)
Radio channels 2.4 GHz
Radio channels 5 GHz
Band Steering
Roaming
WPA2 fast roaming
Fast client roaming
VLAN
Dynamic VLAN assignment
Q-in-Q tagging
Multi-SSID
IGMP snooping
Security
EAP Types
RADIUS server
EAP server
Quality of Service
2400 -2483.5 MHz (ISM) and 5150-5825 MHz (depending on country-specific restrictions)
54 Mbps to IEEE 802.11g (fallback to 48, 36 , 24, 18, 12, 9, 6 Mbps, Automatic Rate Selection) compatible to IEEE 802.11b (11, 5.5, 2, 1 Mbps,
Automatic Rate Selection), 802.11 b/g compatibility mode or pure g or pure b
54 Mbps (fallback to 48, 36 , 24, 18, 12, 9, 6 Mbps, Automatic Rate Selection), fully compatible with TPC (adjustable power output) and DFS
(automatic channel selection, radar detection) according to EN 301 893 and EN 302 502
More than 20 km in 5 GHz. See our LANCOM Antenna Distance Calculator under www.lancom.de
802.11b: +19 dBm @ 1 and 2 Mbps, +19 dBm @ 5.5 und 11 Mbps 802.11g: +18 dBm @ 6 to 36 Mbps, +17 dBm @ 48 Mbps, +16 dBm @ 54
Mbps 802.11n: +19 dBm @ 6,5/13 Mbps (MCS0/8, 20 MHz), +10 dBm @ 65/130 Mbps (MCS7/15, 20 MHz), +17 dBm @ 15/30 Mbps (MCS0/8, 40
MHz), +10 dBm @ 150/300 Mbps (MCS7/15, 40 MHz)
802.11a/h: +18 dBm @ 6 to 24 Mbps, +17 dBm @ 36 Mbps, +16 dBm @ 48 Mbps, +15 dBm @ 54 Mbps 802.11n: +18 dBm @ 6,5/13 Mbps
(MCS0/8, 20 MHz), +10 dBm @ 65/130 Mbps (MCS7/15, 20 MHz), +17 dBm @ 15/30 Mbps (MCS0/8, 40 MHz), +10 dBm @ 150/300 Mbps (MCS7/15,
40 MHz)
802.11b: 18 dBm@ 1 and 2 Mbps | 18 dBm@ 5.5 and 11 Mbps 802.11g: 16 dBm @ 54 Mbps 802.11n: 15 dBm @ 65/130 Mbps (MCS7, 20 MHz)
| 15 dBm @ 150/300 Mbps (MCS7, 40 MHz)
802.11a/h: +12 dBm @ 54 Mbps 802.11n: +12 dBm @ 65/130 Mbps (MCS7, 20 MHz)| +12 dBm @ 150/300 Mbps (MCS7, 40 MHz)
802.11b/g: Up to 20 dBm / 100 mW EIRP (transmission power control according to TPC)
802.11a/h: Up to 30 dBm / 1000 mW or up to 36 dBm / 4000 mW EIRP (depending on national regulations on channel usage and subject to further
obligations such as TPC and DFS)
Transmission power reduction in software in 1 dB steps to min. 0.5 dBm
802.11b: -91 dBm @ 11 Mbps, -96 dBm @ 1 Mbps; 802.11g: -96 dBm @ 6 Mbps, -83 dBm @ 54 Mbps; 802.11n: -96 dBm @ 6,5 Mbps (MCS0, 20
MHz), -79 dBm @ 65 Mbps (MCS7, 20 MHz); -93 dBm @ 13 Mbps (MCS8, 20 MHz), -77 dBm @ 130 Mbps (MCS15, 20 MHz); -90 dBm @ 15 Mbps
(MCS0, 40 MHz), -75 dBm @ 150 Mbps (MCS7, 40 MHz); -90 dBm @ 30 Mbps (MCS8, 40 MHz), -73 dBm @ 300 Mbps (MCS15, 40 MHz)
802.11a/h: -95 dBm @ 6 Mbps, -82 dBm @ 54 Mbps; 802.11n: -95 dBm @ 6,5 Mbps (MCS0, 20 MHz), -77 dBm @ 65 Mbps (MCS7, 20 MHz); -94
dBm @ 13 Mbps (MCS8, 20 MHz), -74 dBm @ 130 Mbps (MCS15, 20 MHz); -91 dBm @ 15 Mbps (MCS0, 40 MHz), -75 dBm @ 150 Mbps (MCS7,
40 MHz); -90 dBm @ 30 Mbps (MCS8, 40 MHz), -71 dBm @ 300 Mbps (MCS15, 40 MHz)
802.11b: -90 dBm @11 Mbps 802.11g: -76 dBm @ 54 Mbps 802.11n: -70 dBm @ 65 Mbps (MCS7, 20 MHz)| -70 dBm @ 150 Mbps (MCS7, 40
MHz)
802.11a/h: -76 dBm @ 54 Mbps 802.11n: -69 dBm@ 65 Mbps (MCS7, 20 MHz) | -68 dBm @ 150 Mbps (MCS7, 40 MHz)
Up to 13 channels, max. 3 non-overlapping (depending on country-specific restrictions)
Up to 26 non-overlapping channels (available channels and further obligations such as automatic DFS dynamic channel selection depending on
national regulations)
Steering of WLAN clients towards the 5 GHz frequency band by restricting the access to the 2.4 GHz band.
Seamless handover between radio cells, IAPP support with optional restriction to an ARF context, IEEE 802.11d support
Pre-authentication and PMK caching for fast roaming
With background scanning, moving LANCOM 'client mode' access points pre-authenticate to alternative access points which offer a better signal
before Roaming fails
VLAN ID definable per interface, WLAN SSID, point-to-point connection and routing context (4094 IDs) IEEE 802.1q
Dynamic VLAN assignment for target user groups based on MAC addresses, BSSID or SSID by means of external RADIUS server.
Support of layered 802.1Q VLANs (double tagging)
Simultaneous use of up to 8 independent WLAN networks per WLAN interface
Support for Internet Group Management Protocol (IGMP) in the WLAN bridge for WLAN SSIDs and LAN interfaces for specific switching of multicast
packets (devices with integrated WLAN only). Automated detection of multicast groups. Configurable action for multicast packets without registration.
Configuration of static multicast group members per VLAN ID. Configuration of query simulation for multicast membership per VLAN ID
IEEE 802.11i / WPA2 with passphrase (WPA2-Personal) or 802.1X (WPA2-Enterprise) and hardware-accelerated AES, closed network, WEP64,
WEP128, WEP152, user authentication, 802.1x /EAP, LEPS, WPA1/TKIP
EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC, EAP-SIM, EAP-AKA, EAP-AKA Prime, EAP-FAST
Integrated RADIUS server for MAC address list management
Integrated EAP server for authentication of 802.1X clients via EAP-TLS, EAP-TTLS, PEAP, MSCHAP or MSCHAPv2
Prioritization according to Wireless Multimedia Extensions (WME, subset of IEEE 802.11e)
Features as of: LCOS 8.82
