Lancom OAP-382 Brochure & Specs page 5

LANCOM OAP-382
Firewall
Tagging
Actions
Notification
Quality of Service
Traffic shaping
Bandwidth reservation
DiffServ/TOS
Packet-size control
Layer 2/Layer 3 tagging
Security
Intrusion Prevention
IP spoofing
Access control lists
Denial of Service protection
General
URL blocker
Password protection
Alerts
Authentication mechanisms
WLAN protocol filters
IP redirect
High availability / redundancy
VRRP
FirmSafe
Line monitoring
Routing functions
Router
Advanced Routing and Forwarding
HTTP
DNS
DHCP
NetBIOS
NTP
Policy-based routing
Dynamic routing
The firewall marks packets with routing tags, e.g. for policy-based routing; Source routing tags for the creation of independent firewall rules for
different ARF contexts
Forward, drop, reject, block sender address, close destination port, disconnect
Via e-mail, SYSLOG or SNMP trap
Dynamic bandwidth management with IP traffic shaping
Dynamic reservation of minimum and maximum bandwidths, totally or connection based, separate settings for send and receive directions. Setting
relative bandwidth limits for QoS in percent
Priority queuing of packets based on DiffServ/TOS fields
Automatic packet-size control by fragmentation or Path Maximum Transmission Unit (PMTU) adjustment
Automatic or fixed translation of layer-2 priority information (IEEE 802.11p-marked Ethernet frames) to layer-3 DiffServ attributes in routing mode.
Translation from layer 3 to layer 2 with automatic recognition of 802.11p-support in the destination device
Monitoring and blocking of login attempts and port scans
Source IP address check on all interfaces: only IP addresses belonging to the defined IP networks are allowed
Filtering of IP or MAC addresses and preset protocols for configuration access
Protection from fragmentation errors and SYN flooding
Detailed settings for handling reassembly, PING, stealth mode and AUTH port
Filtering of unwanted URLs based on DNS hitlists and wildcard filters
Password-protected configuration access can be set for each interface
Alerts via e-mail, SNMP-Traps and SYSLOG
EAP-TLS, EAP-TTLS, PEAP, MS-CHAP, MS-CHAPv2 as EAP authentication mechanisms, PAP, CHAP, MS-CHAP and MS-CHAPv2 as PPP authentication
mechanisms
Limitation of the allowed transfer protocols, source and target addresses on the WLAN interface
Fixed redirection of any packet received over the WLAN interface to a dedicated target address
VRRP (Virtual Router Redundancy Protocol) for backup in case of failure of a device or remote station. Enables passive standby groups or reciprocal
backup between multiple active devices including load balancing and user definable backup priorities
For completely safe software upgrades thanks to two stored firmware versions, incl. test mode for firmware updates
Line monitoring with LCP echo monitoring, dead-peer detection and up to 4 addresses for end-to-end monitoring with ICMP polling
IP and NetBIOS/IP multi-protocol router
Separate processing of 16 contexts due to virtualization of the routers. Mapping to VLANs and complete independent management and configuration
of IP networks in the device, i.e. individual settings for DHCP, DNS, Firewalling, QoS, VLAN, Routing etc. Automatic learning of routing tags for
ARF contexts from the routing table
HTTP and HTTPS server for configuration by web interface
DNS client, DNS server, DNS relay, DNS proxy and dynamic DNS client
DHCP client, DHCP relay and DHCP server with autodetection. Cluster of several LANCOM DHCP servers per context (ARF network) enables caching
of all DNS assignments at each router. DHCP forwarding to multiple (redundant) DHCP servers
NetBIOS/IP proxy
NTP client and SNTP server, automatic adjustment for daylight-saving time
Policy-based routing based on routing tags. Based on firewall rules, certain data types are marked for specific routing, e.g. to particular remote
sites or lines
Dynamic routing with RIPv2. Learning and propagating routes; separate settings for LAN and WAN. Extended RIPv2 including HopCount, Poisoned
Reverse, Triggered Update for LAN (acc. to RFC 2453) and WAN (acc. to RFC 2091) as well as filter options for propagation of routes. Definition
of RIP sources with wildcards
Features as of: LCOS 8.82
