- Page 1 FEP-1601 16 FE PoE Switch User Manual Ver 1.0...
- Page 2 1. Introductions Thank you for purchasing the 16-Port PoE Switch. The 16-Port PoE Switch, is a 16-port 10/100Mbps Fast Ethernet Switch with Power over Ethernet capability. With 16 dip switches, each PoE port can be manually set for On-Off control. 16-Port PoE Switch supports up to 15.4W/30W on each LAN port when the corresponding port DIP switch is set ON.
-
Page 3: Technical Specifications
3. Packing Contents Inside the package you shall find: (1) 19” 16-Port FE PoE Switch (2) Power Cord (3) User Manual Please check if the packing is damaged or any component is missing. If so, please contact your distributor. 4. Technical Specifications IEEE 802.3 10BaseT IEEE 802.3u 100BaseTX Standards... - Page 4 6. Dip Switch Settings vs Power over Ethernet 1 ~ 16 ports DIP ON Per PoE Port 15.4/30WWatts Injected Maximum PoE Power 240 Watts Note that the dip switches can be switched ON and OFF anytime. However, it is suggested that the dip switches be set ready before the PoE port is connected for power management.
