FEP-1601 Version: 1
16-Port Fast Ethernet PoE Switch
FEP-1601 is a 16-port 10/100Mbps Fast Ethernet Switch with Power over Ethernet (PoE) capability. With
16 dip switches, each PoE port can be manually set for On-Off control. FEP-1601 supports up to 30W on
each LAN port when the DIP switch is in the ON position . Using a LevelOne PoE repeater, it is possible to
extend the connection a further 100 meters, or even daisy-chain several PoE repeaters together for greater
distances. Dual 10/100Mbps ports can connect with other edge switches or NVR as uplink ports
Key Features
- IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
- 10/100Mbps, full/half-duplex, auto-negotiation, auto-MDI/MDIX
- PoE on/off control per port by dip switches
- 19-inch metal housing
-
Specifications
System Specifications
Standards & Protocols:
IEEE 802.3 10-BASE-T, Ethernet
IEEE 802.3u 100-BASE-TX, Fast Ethernet
IEEE 802.3x Full-duplex Flow Control
www.level1.com
Page 1 of 3
Advertisement
Related Manuals for LevelOne FEP-1601
Summary of Contents for LevelOne FEP-1601
- Page 1 16 dip switches, each PoE port can be manually set for On-Off control. FEP-1601 supports up to 30W on each LAN port when the DIP switch is in the ON position . Using a LevelOne PoE repeater, it is possible to extend the connection a further 100 meters, or even daisy-chain several PoE repeaters together for greater distances.
- Page 2 Power, Active, 10/100M, PoE Transmission Method: Store-and-Forward Power Input: 100-240V AC, 50-60 Hz, 5A, Internal Power Supply Power Consumption: < 120W (FEP-1601W120) < 150W (FEP-1601W150) < 250W (FEP-1601) < 380W (FEP-1601W380) Features PoE: Power Budget: Max.112W (FEP-1601W120) Max.142W (FEP-1601W150) Max.242W (FEP-1601) Max.372W (FEP-1601W380) Power Output: 56V DC, up to 30W per port Protection: PoE over current &...
-
Page 3: Order Information
480 × 118 × 44 mm Weight (g): 2200g Approval and Compliance EMI/EMS: FCC, CE, RoHS Diagram Order Information FEP-1601: 250W FEP-1601W120: 120W FEP-1601W150: 150W FEP-1601W380: 380W Package Contents FEP-1601 Power Cord User Manual No liability or responsibility for any errors or omissions in the content.
