- Page 1 FEP-2402 Series 24-Port Fast Ethernet PoE Switch, 802.3at/af PoE User Manual...
- Page 2 1. Introductions Thank you for purchasing the PoE Switch. The PoE Switch, is a 24-port 10M/100M PoE + 2-port 1000M (SFP) Switch with PoE On/Off control capability. With 24 dip switches, each PoE port can be manually set for On-Off control. 24-Port PoE Switch supports up to 30W on each LAN port when the corresponding port DIP switch is set ON.
- Page 3 Please check if the packing is damaged or any component is missing. If so, please contact your distributor. 4. Technical Specifications IEEE 802.3/u 10/100/1000BaseT/TX/FX IEEE 802.3x Flow Control Standards IEEE 802.3at/af PoE compliant midspan PoE compliant MAC Address: 8K Features Buffer Memory: 512KB Transmission Method: Store and Forward 1000Mbps port –...
- Page 4 5. LED Indicators On the front panel of 24-Port FE PoE + 2-Port GE Switch, there are LED indicators as the following; “Green POWER: On” indicates power is on and normal. “Green Port 1~24 LAN: On” indicates each Ethernet LAN port is in connection. “Green GbE Port 25, 26: On”...
