Summary of Contents for LevelOne FEP-2401 Series
Page 1
FEP-2401 Series 24-Port Fast Ethernet PoE Switch, 802.3at/af PoE User Manual...
Page 2
1. Introductions Thank you for purchasing the PoE Switch. The PoE Switch, is a 24-port 10M/100M PoE + 2-port 10M/100M/1000M(UTP) Switch with PoE On/Off control capability. With 24 dip switches, each PoE port can be manually set for On-Off control. 24-Port PoE Switch supports up to 30W on each LAN port when the corresponding port DIP switch is set ON.
Page 3
4. Technical Specifications IEEE 802.3/u 10/100/1000BaseT/TX IEEE 802.3x Flow Control Standards IEEE 802.3at/af PoE compliant midspan PoE compliant MAC Address: 8K Buffer Memory: 512KB Features Transmission Method: Store and Forward 1000Mbps port – 1,488,000pps 100Mbps port - 148,800pps Filtering/Forwarding Rates 10Mbps port - 14,880pps 10BaseT Cat.
Page 4
5. LED Indicators “Green POWER: On” indicates power is on and normal. “Green Port 1~24 LAN: On” indicates each Ethernet LAN port is in connection. “Green GbE Port 25, 26: On” indicates Gigabit LAN port is in connection. “Yellow On” indicates Fast Ethernet LAN port is in connection. “Green PoE: On”...
