SY-6VBA 133 Quick Start Guide

Quick BIOS Setup

3
3
This Motherboard does not use any hardware jumpers to set the CPU frequency. Instead,
CPU settings are software configurable with the BIOS [SOYO COMBO SETUP]. The
[SOYO COMBO SETUP] menu combines the main parameters that you need to configure,
all in one menu, for a quick setup in BIOS.
After the hardware installation is complete, turn the power switch on, then press the <DEL> key
during the system diagnostic checks to enter the Award BIOS Setup program. The CMOS
SETUP UTILITY will display on screen. Then, follow these steps to configure the CPU settings.
Step 1. Select [STANDARD CMOS SETUP]
Set [Date/Time] and [Floppy drive type], then set [Hard Disk Type] to " Auto" .
Step 2. Select [LOAD SETUP DEFAULT]
Select the " LOAD SETUP DEFAULT" menu and type " Y" at the prompt to load the BIOS
optimal setup.
Step 3. Select [SOYO COMBO SETUP]
Move the cursor to the [CPU Frequency] field to set the CPU frequency.
Available [CPU Frequency] settings on your SY-6VBA 133 Motherboard are detailed in the
following table.
CPU Frequency (MHz)
Manual
200MHz (66 x 3.0)
233MHz (66 x 3.5)
266MHz (66 x 4.0)
300MHz (66 x 4.5)
333MHz (66 x 5.0)
366MHz (66 x 5.5)
400MHz (66 x 6.0)
433MHz (66 x 6.5)
466MHz ( 66 x 7.0)
Select the working frequency of your Pentium
these preset values.
Note: Mark the checkbox that corresponds to the working frequency of your Pentium
®
III, Pentium II, Celeron™ processor in case the CMOS configuration should be lost.
500MHz( 66 x 7.5)
533MHz ( 66 x 8.0)
300MHz (100 x 3.0)
350MHz (100 x 3.5)
400MHz (100 x 4.0)
450MHz (100 x 4.5)
500MHz (100 x 5.0)
550MHz (100 x 5.5)
600MHz (100 x 6.0)
650MHz (100 x 6.5)
700MHz(100 x 7.0)
® ®
III, Pentium II, Celeron™ processor among
12
750MHz (100 x 7.5)
800MHz (100 x 8.0)
400MHz (133 x 3.0)
466MHz (133 x 3.5)
533MHz (133 x 4.0)
600MHz (133 x 4.5)
666MHz (133 x 5.0)
733MHz (133 x 5.5)
800MHz (133 x 6.0)
866MHz (133 x 6.5)
933MHz (133 x 7.0)
®
