System board

NOTE: The system board spare part kit includes replacement thermal material.
Description
Intel Pentium N3520 processor and the Windows 8.1 Standard operating system
Intel Pentium N3520 processor and a non-Windows 8 operating system
Intel Celeron N2820 processor and the Windows 8.1 Standard operating system
Intel Celeron N2820 processor and a non-Windows 8 operating system
Before removing the system board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see
5. Remove the battery (see
NOTE: When replacing the system board, be sure that the following components are removed from the
defective system board and installed on the replacement system board:
●
WLAN module (see
● WWAN module (see
● Memory module (see
● Heat sink (see
●
Fan (see
Remove the system board:
1. Disconnect the following cables from the system board:
(1): Power connector cable
(2): Wireless antennas (may include one or two antennas)
(3): Keyboard cable
(4): Webcam cable
(5): Display cable
(6): Power button board cable
(7): Fan cable
(8): Speaker cable
(9): Touchpad board cable
(10): Hard drive cable
60 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
Bottom cover on page
Battery on page
WLAN module on page
WWAN module on page
Memory module on page
Heat sink on page 46)
Fan on page 45)
28).
49).
32)
34)
41)
Spare part number
755724-501
755724-001
755723-501
755723-001
