Display Assembly - HP Pavilion 11 x360 PC Maintenance And Service Manual

Display assembly

Description
Display assembly (11.6-in [29.5-cm] HD, anti-glare, touchscreen, for use in red models without WWAN
Display assembly, 11.6-in [29.5-cm] HD, anti-glare, touchscreen, for use in red models with WWAN
Webcam
Display cable
Display enclosure for use in silver models
Display enclosure for use in red models
Hinge covers for use in red models
Hinge covers for use in silver models
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the bottom cover (see
5. Remove the battery (see
To remove the display assembly:
1. Release the wireless antenna cables from the clips (1) built into the base enclosure.
NOTE:
2. Disconnect the webcam cable (2) from the system board.
Bottom cover on page
Battery on page
The number of antenna cables may vary.
28).
49).
Component replacement procedures
Spare part number
755730-001
756108-001
758848-001
761350-001
758845-001
758846-001
758847-001
759503-001
53
