HP Pavilion 11 x360 PC Maintenance And Service Manual page 10

Category
Ethernet
Sensor
Wireless
External media cards
Ports
Keyboard/pointing devices
Power requirements
2 Chapter 1 Product description
Description
Beats Audio
Dual Speakers support 25 mm x 14 mm speaker
Formats: MP3, AAC,AAC+, EAAC+ OGG, MIDI
Integrated 10/100 network interface card (NIC)
Co-layout with Giga-LAN
Sensor Hub (Accelerometer + Gyroscope + e-Compass)
Support Proximity Sensor for SAR certification (WWAN option)
Integrated wireless local area network (WLAN) options by way of wireless module
Support for the following WLAN formats:
●
Atheros AR9485 802.11b/g/n WiFi Adapter with 1 antenna
● Qualcomm QCA9565 802.11bgn 1x1 Wi-Fi + BT4.0 Combo Adapter with 1 antenna
● Ralink RT3290LE 802.11b/g/n 1×1 WiFi and Bluetooth 4.0 Combo Adapter with 1 antenna
● Realtek RTL8188EE 802.11bgn Wi-Fi Adapter with 1 antenna
Integrated wireless wide area network (WWAN) options by way of wireless module
Support for the following WWAN formats:
HP hs3110 HSPA+ Mobile Broadband Module
Compatible with Miracast-certified devices
HP Multi-Format Digital Media Card Reader with push-push technology. Supports SD/SDHC/SDXC.
SIM card slot
● AC adapter: HP Smart pin plug (4.5-mm barrel)
● Audio: one combo audio-out (headphone)/audio-in (microphone) jack, supports jack auto-
detection
● HDMI: v. 1.4, supporting up to 1080p, 1920×1080 at 60 Hz
● RJ-45/Ethernet
●
(1) USB 3.0
● (2) USB 2.0
● Video: VGA (Dsub 15-pin) supporting 1920×1200 external resolution at 60 Hz, hot plug/
unplug and auto-detection for correct output to wide-aspect vs. standard aspect video
97%-size, textured, island-style keyboard (no numerical keypad)
Touchpad requirements:
HP Imagepad - Clickpad with image sensor
Taps enabled as default
Multitouch gestures enabled: 2-finger scroll, pinch
Support for PS/2 and SMB interface
Support for Windows 8.1 Modern TouchPad Gestures
Support for the following AC adapters:
● 45-W HP Smart AC adapter (non-PFC, MSH) (for Germany only)
