LSI22902/22903 Host Adapter
to Intel ISP1100 Internet Server
Quick Installation Guide
The LSI Logic LSI22902/22903 PCI to Dual Channel Ultra2 SCSI Low
Profile Host Adapter is ideally suited for installation into the Intel ISP1100
Internet Server Platform. In this application, the host adapter provides
one internal LVD only channel and one LVD or SE external channel.
1 Overview
This document describes installing the LSI22902/22903 into the Intel
ISP1100 Internet Server Platform. The host adapter kit includes the
following items. Refer to
November 2000
Copyright © 2000 by LSI Logic Corporation. All rights reserved.
LSI22902 or LSI22903 Host Adapter.
Host Adapter user's guide.
This manual contains detailed engineering documentation for the
LSI22902/22903.
PCI Storage Device Management SDMS 4.0 CD.
This CD contains software and associated documentation for the
LSI22902.
Internal SCSI cable with attached Ultra2 LVD terminator.
High Density (HD) LED connector.
An additional card guide for a standard PC chassis.
Figure 1
for a picture of the complete kit.
®
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the LSI22902 and is the answer not in the manual?

Questions and answers

Summary of Contents for LSI LSI22902

  • Page 1 Intel ISP1100 Internet Server Quick Installation Guide The LSI Logic LSI22902/22903 PCI to Dual Channel Ultra2 SCSI Low Profile Host Adapter is ideally suited for installation into the Intel ISP1100 Internet Server Platform. In this application, the host adapter provides one internal LVD only channel and one LVD or SE external channel.
  • Page 2 The installation process contains the following four major sections: • Section 2.1, “Setting up the Installation” • Section 2.2, “Installing the Host Adapter Board” • Section 2.3, “Installing New Drives” • Section 2.4, “Completing the Installation” LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 3 Make sure the ISP1100 server is turned off and is not plugged into an electrical outlet. Take all precautions to minimize ESD. A ground strap is recommended. Step 1. Identify the parts listed below on the LSI22902/22903. Refer to Figure 2 for a photograph of the board.
  • Page 4 The slot on the right side of the riser card. d. Slimline floppy cable. White cable approximately 1 inch wide. e. IDE cables for hard drives and CD-ROM. Gray cables approximately 2 inches wide. LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 5 2.2 Installing the Host Adapter Board This section of the manual describes setting up the Intel ISP1100 server and installing the LSI22902/22903 and other system hardware. Step 1. Identify the PCI low profile slot for the host adapter board. LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 6 64-bit PCI SCSI host adapter card, but it provides full functionality in the 32-bit slots of the ISP1100. 2.2.1 LSI22902 Installation Method 1 Follow these steps to install the LSI22902/22903 into the ISP1100. Refer Figure 6 for a photograph of the Method 1 installation.
  • Page 7 There is no screw securing the card guide bracket in place as in a PC. Step 3. Secure the expansion bay retention clip with the two previously removed screws. Figure 6 Method 1 Installation LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 8 2.2.2 LSI22902 Installation Method 2 Method 2 is different from the first method in that you remove the riser card from the ISP1100 to insert the LSI22902/22903, rather than doing it in place as in Method 1. Refer to Figure 7 for a photograph showing the host adapter installed in the riser card.
  • Page 9 Do not disconnect this cable from the mainboard. Step 7. Remove the CD-ROM cable and power cable as shown in Figure Press the cable ejector tabs on both sides of the cable and disconnect the CD-ROM power cable. LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 10 Figure 8 Floppy Cable Location LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 11 Step 1. Remove the slimline CD-ROM and floppy assembly from the ISP1100 by removing the three screws holding the assembly to the chassis. Refer to Figure 10 for a photograph of the Slimline CD-ROM/floppy assembly. LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 12 Step 3. Mount the two LVD SCSI hard drives in the bays according to the installation instructions from the original equipment manufacturer. Refer to the inset photograph in Figure LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 13 Step 4. Remove the IDE cable by carefully detaching it from the mainboard connector, J27, if present. Refer to Figure 12 for a photograph showing the cable and its location. As noted above, it may not be present. LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 14 Step 8. Lay the floppy cable back on top of the SCSI cable. Be sure to slide the cable under the fan assembly bracket. Refer to Figure 13 for a photograph showing a recommended SCSI cable routing. LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 15 Step 11. Attach the SCSI and power cable for each drive. The SCSI cable terminator should position itself between the two drive bays. Refer to Figure 14 for a photograph showing drive bay installation. LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 16 Step 13. Connect the IDE secondary channel cable and the power cable for the CD-ROM. Step 14. Connect the floppy cable. Refer to Figure 15 for a photograph of the CD-ROM and floppy drive installation. LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 17: Completing The Installation

    The Intel ISP1100 Internet Server is now ready to be mounted into a rack mount system and is ready for software installation. For additional assistance in the PCI to SCSI host adapter board installation process, contact LSI Logic technical support (support@lsil.com). LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 18 Figure 16 Attaching the Hard Drive LED Activity Cable LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 19 Notes LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server...
  • Page 20 LSI Logic; nor does the purchase, lease, or use of a product or service from LSI Logic convey a license...
