RJ-45 Connector
The RJ-45 connector, which is covered by a removable plate, is used to connect a management station
device or a test device. This connector is used by field engineers to perform testing and to obtain dump
information.
SSL Connector
The Certificate Management (Cert. Mgt.) port connector is used for SSL certificate management and is
available to make the necessary connection to the SSL daughter card for initial configuration purposes.
After the initial configurations, you can make an SSH or Telnet connection to further configure the
module. See Chapter 5 in the Catalyst 6500 Series Content Switching Module with SSL Installation and
Configuration Note.
Environmental and System Requirements
These sections describe the environmental and system requirements:
•
•
•
•
•
•
•
Environmental Requirements
Table 2
Item
Temperature, ambient operating
Temperature, ambient nonoperating
Humidity (RH), ambient (noncondensing)
operating
Nonoperating relative humidity (noncondensing) 5% to 95%
78-16856-01
lists the environmental requirements for the CSM-S.
CSM-S Environmental Requirements
Catalyst 6500 Series Switch Content Switching Module with SSL Installation Note
Environmental and System Requirements
Specification
o
o
o
o
0
to 40
C (32
to 104
F)
o
o
o
o
-40
to 70
C (-40
to 158
10% to 90%
F)
9
