Horizon Fitness M4 Owner's Manual
  1. Manuals
  2. Brands
  3. Horizon Fitness Manuals
  4. Exercise Bike
  5. M4
  6. Owner's manual

Horizon Fitness M4 Owner's Manual

Indoor cycle
Hide thumbs Also See for M4:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
4
M
INDOOR CYCLE OWNER'S MANUAL
M4-owners-manual-Rev1_2.indd 1
9/13/11 2:07 PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M4 and is the answer not in the manual?

Questions and answers

Related Manuals for Horizon Fitness M4

Summary of Contents for Horizon Fitness M4

  • Page 1 INDOOR CYCLE OWNER’S MANUAL M4-owners-manual-Rev1_2.indd 1 9/13/11 2:07 PM...

  • Page 2: Important Precautions

    It is the responsibility of the owner to ensure that all users of this indoor cycle are adequately informed of all warnings and precautions. If you have any questions after reading this owner’s manual, contact Customer Tech Support at the number listed on the back panel. M4-owners-manual-Rev1_2.indd 2-3 9/13/11 2:07 PM...
  • Page 3 If the assembly instructions are not followed correctly, the • Never operate the cycle if it is not working properly, or if it has been damaged. Contact Horizon Fitness or the authorized dealers for indoor cycle could have parts that are not tightened and will seem loose and may cause irritating noises.

  • Page 4: Pre-Assembly

    If you have questions or if there are any missing parts, contact Computer Shown unattached Customer Tech Support. Computer Bracket Contact information is located on the back panel of this manual. Self-tapping Screw ST 4.2 x 25 L M4-owners-manual-Rev1_2.indd 6-7 9/13/11 2:07 PM...

  • Page 5: Assembly Step 1

    (8), and secure firmly by Allen Wrench (6). right side arm of the cycle using the Combination Wrench (5). Please note that the R pedal is right-hand threaded which needs to be turned clockwise to tighten. M4-owners-manual-Rev1_2.indd 8-9 9/13/11 2:07 PM...
  • Page 6 (sensor) into firmly by Allen Wrench (6). firmly by Allen Wrench (6) and the groove of the bracket on the then slide the computer (11) front fork of the indoor cycle. into the bracket. ASSEMBLY COMPLETE! M4-owners-manual-Rev1_2.indd 10-11 9/13/11 2:08 PM...

  • Page 7: Model Information

    TENSION CONTROL & EmERgENCy bRAkE: friction brake with micro-adjustable knob and push-down emergency stop. NOTE: In case of emergency, you may press directly down on the Tension Control knob to bring the flywheel to an abrupt stop. M4-owners-manual-Rev1_2.indd 12-13 9/13/11 2:08 PM...

  • Page 8: Saddle Adjustment

    The Indoor Cycle should not be 6 ft 183 cm located in a garage, covered patio, near water or outdoors. Leveling Feet M4-owners-manual-Rev1_2.indd 14-15 9/13/11 2:08 PM...
  • Page 9 Repeat for the saddle slide for proper operation. other foot. Keep your knees over your feet as you pedal. To remove your foot from the toe clip, loosen the strap and pull out. M4-owners-manual-Rev1_2.indd 16-17 9/13/11 2:08 PM...
  • Page 10 ODOmETER: monitor will display the total accumulated distance emergency stop CALORIE: Count the total calories from exercise start to end bATTERIES: 2, size AA NOTE: Distance and speed are displayed as Miles. Kilometers are not available on this console. M4-owners-manual-Rev1_2.indd 18-19 9/13/11 2:08 PM...

  • Page 11: Troubleshooting And Maintenance

    TROUBLESHOOTING & MAINTENANCE M4-owners-manual-Rev1_2.indd 20-21 9/13/11 2:08 PM...

  • Page 12: Common Product Questions

    Indoor Cycle should be in a comfortable setting. Answering these and other questions will give the technicians the ability to send proper replacement parts and the service necessary to get you and your Indoor Cycle running again! M4-owners-manual-Rev1_2.indd 22-23 9/13/11 2:08 PM...

  • Page 13: Maintenance

    Similarly, apply some light grease to the clamping assembly to ensure it does not seize up. Clean off excessive grease before reassembly. • Please lubricate the seat post, brake pad and handlebar adjustment regularly with lubricant in your parts package. M4-owners-manual-Rev1_2.indd 24-25 9/13/11 2:08 PM...

  • Page 14: Limited Home Use Warranty

    • Any attempt to repair this equipment creates a risk of injury. Horizon Fitness is not responsible or liable for any damage, loss or liability arising from any personal injury...
  • Page 15 1-800-244-4192 Horizon fitness comments@horizonfitness.com 1600 Landmark Drive, www.horizonfitness.com Cottage grove wI, 53527 M4 Rev. 1.2 | © 2011 Johnson Health Tech North America, Inc. | Designed & Engineered in the U.S.A. | Made in China M4-owners-manual-Rev1_2.indd 28 9/13/11 2:08 PM...
