Summary of Contents for INSTEON 2475DA2
- Page 1 Ballast Dimmer ® INSTEON Remote Control 0-10VDC Ballast Dimmer Owner’s Manual 2475DA2 (US) 2442-422 (EU) 2442-522 (AUS/NZ) Page 1 of 16 2475DA2, 2442-422, 2442-522 Rev: 1/21/2014 8:31 AM...
-
Page 2: Table Of Contents
Phase Bridge Detect Beacon/RF Range Test ..................14 Certification and Warranty ........................15 Certification .............................. 15 FCC and Industry Canada Compliance Statement ................. 15 Limited Warranty ............................. 15 Limitations ............................15 Page 2 of 16 2475DA2, 2442-422, 2442-522 Rev: 1/21/2014 8:31 AM... -
Page 3: About Ballast Dimmer
Optional Accessories Ballast Dimmer Slotted screwdriver Keypad Dimmer Quick Start Guide Phillips screwdriver Dimmer Switch Mounting Screws Wire cutter/stripper INSTEON Hub Two extra INSTEON ID labels Voltage meter Mini Remote Page 3 of 16 2475DA2, 2442-422, 2442-522 Rev: 1/21/2014 8:31 AM... -
Page 4: Getting Started
Map out the wall switch and load that you are going to remotely operate. Keep in mind that you are going to replace the existing wall switch with a keypad or another INSTEON controller where both are wired to the same constant hot line using the existing wiring. -
Page 5: Install Ballast Dimmer For Dimmable Ballast
Ballast Dimmer load will respond appropriately Link Ballast Dimmer to your INSTEON keypad or other INSTEON controller. See Make Ballast Dimmer a Responder Gently place Ballast Dimmer into the fixture box, making sure nothing could accidentally press the set button... -
Page 6: Installing Ballast Dimmer In Dual-Relay Mode
Test the Ballast Dimmer connection by tapping set button a couple times Link Ballast Dimmer to your INSTEON keypad or other INSTEON controller. See Make Ballast Dimmer a Responder Gently place Ballast Dimmer into the fixture box, making sure nothing could accidentally press the set button... -
Page 7: Insteon Setup
Please note that a link is one way. If you wish to have control “the other way,” simply repeat link setup process “the other way.” Most INSTEON devices can store hundreds of links. Furthermore, a controller can simultaneously control from 1 to hundreds of responders using what are called groups and scenes. Each link can have its own properties (e.g. -
Page 8: Changing Operating Modes (Dimmer Or Switch)
Red, Green, Green, Green = Relay Mode Scenes INSTEON scenes allow a controller to conveniently adjust multiple responders to any number of desired levels, all simultaneously. Software is recommended when setting up and maintaining scenes, especially larger scenes. Create a scene with 1 controller and Ballast Dimmer as a member... -
Page 9: X10 Setup
If either controller or responder LED continues blinking, the addition failed. Tap device’s set button until LED stops blinking and try linking again. For devices without beepers hold until its LED begins blinking (this may take 10+ seconds) Page 9 of 16 2475DA2, 2442-422, 2442-522 Rev: 1/21/2014 8:31 AM... -
Page 10: Remove Ballast Dimmer As A Controller
Ballast Dimmer will double-beep and the load will turn on Restoring Power Ballast Dimmer stores all of its settings, such as links to other INSTEON devices, with non-volatile memory. Because settings are saved in this non-volatile memory, they will not be lost in the event of a power failure. -
Page 11: Specifications
Specifications General Ballast Dimmer Relay – INSTEON Remote Control Ballast Product Name Dimmer On/Off Switch (Dual-Band) Brand INSTEON 2475DA2 (US) Manufacturer Product Number 2446-422 (EU) 2446-522 (AUS/NZ) 813922011425 (US) 813922012897 (EU) 813922012903 (AZ) Patent Number 7,345,998 US, International Patents Granted and Pending... - Page 12 Wired in ballasted dimming and non-dimming lighting loads Retains all settings without power Yes, saved in Non-volatile EEPROM Standby power consumption < 1 watt Safety Approved ETL, CE, C-Tick Page 12 of 16 2475DA2, 2442-422, 2442-522 Rev: 1/21/2014 8:31 AM...
- Page 13 FCC 15.107, 15.109, 15.249 RSS 210 EN 300 220-2, 301 489-3 Certifications AS/NZS 4268, CISPR 22 UL 508 CSA C22.2#14 IEC 60669-2-1 FCC ID SBP2475DA2 Page 13 of 16 2475DA2, 2442-422, 2442-522 Rev: 1/21/2014 8:31 AM...
-
Page 14: Troubleshooting
Ballast Dimmer automatically bridges the electrical phases in your home (via communications with other dual-band devices on the “other phase”). This is only important in 2-phase homes with powerline-only INSTEON products or buildings with both 2- and 3- phase circuits. The phase bridge detect beacon can also be used as an RF range test to... -
Page 15: Certification And Warranty
The repair, replacement, or refund that is provided for above shall be the full extent of Seller’s liability with respect to this product. For repair or replacement during the warranty period, call the INSTEON Support Line at 866-243-8022 with the Model # and... - Page 16 You may also have other legal rights that may vary from state to state. Protected under US and foreign patents (see www.insteon.com/patents) © Copyright 2013 INSTEON, 16542 Millikan Ave., Irvine, CA 92606, 866-243-8022, www.insteon.com Page 16 of 16...
