- Page 1 Ez-Electric Screen Elite Vmax Series -TYPE C- USER’S GUIDE MATTE WHITE Rev 1.2...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS 1. Position the power cord so it will not be tripped over, pulled, or near a hot area or surface. 2. To avoid an electric shock, do not attempt to disassemble this appliance yourself. Contact Elite’s Screens service dept. for help with repairing your screen. 3.
- Page 3 “L” Brackets diagram 6-3/4” Length 1” Width 6-3/4” Height Find the studs on your wall or use drywall anchors to install L brackets to the desired location. Top of “L” bracket from top view Accessories For “L” Bracket Rev 1.2...
- Page 4 “L Brackets Installation Wood/Dry Wall installation: Use “B” wood screws provided for installation on wood studs on wall. Or use “E” hollow wall anchors provided in conjunction with the wood screws for dry wall installation as shown on Fig. 1 Fig.
- Page 5 OPERATION Remote Control System: Line Switch: Manual 3-way wall switch for your new Elite Screen with wirelessIR and RF remote. 1. This is the control box connection to your new Elite Screen. First insert the 3-prong cable (Pins) to the bottom of the control box. Then connect the cord with the 4-prong cable (Pins) into the top end of the control box.
- Page 6 Vertical Limit Switch Adjustment Caution: Screen may be severely damaged if viewing surface is allowed to run too far UP/DOWN. Back Of Screen Up Vertical Position Down Vertical Position Your screen has been set to drop all the way down and to rise all the way up. However, in the event that your screen does not please use the instructions below to adjust the drop/rise to the desired position.
- Page 7 TROUBLESHOOTING If the electric screen does not move, please check the following: 1. Check the power supply and fuse first. The screen will not move without power. 2. Make sure the power cord is plugged to the power outlet. 3. Check all cable connections to see any may be disconnected. 4.
- Page 8 NOTE: Regardless of mounting method, screen should be securely supported so that vibration or even abusive pulling on the viewing surface will not cause case to work loose or fall. Installer must insure that fasteners used are of adequate strength and suitable for the mounting surface chosen.
