Partition & Security Function

Partition Types

You can partition JetFlash into two partition types. The two types are:
Type 1: "Public Area Only"
This is the default partition type for JetFlash. It allows the entire volume of JetFlash memory to be
accessed by anyone. No secure data area is established.
Public Area
Type 2: "Public and Security Area"
JetFlash is partitioned into a single Logical Unit Number (LUN) identified device, which contains a
Public Area and a Security Area. Secure data can be established in the Security Area, which is
protected by a password. Access to data in the Public Area is unrestricted.
Log Out / Log In
Security Area
Public Area
1. Put the Driver CD into the CD-ROM drive (Auto-Run supported). Plug your JetFlash into an
available USB port of your computer and select the mFormat button.
2. Select the Partition button in the mFormat window.
3
