32MB–4GB JetFlash™
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 32MB4GB and is the answer not in the manual?

Questions and answers

Related Manuals for Transcend 32MB4GB

Summary of Contents for Transcend 32MB4GB

  • Page 1 32MB–4GB JetFlash™ User’s Manual...

  • Page 2: Table Of Contents

    Introduction Package Contents ...1 Features ...1 System Requirements ...2 Driver Installation Driver Installation for Windows 98/98SE ...2 Driver Installation for Windows Me, 2000, and XP ...3 Driver Installation for Mac OS 9.0 or Later ...3 Driver Installation for Linux Kernel 2.4 or Later...3 Uninstall the Win98 Driver How to Safely Unplug JetFlash To Remove JetFlash in Windows 98/98SE ...4...

  • Page 3: Package Contents

    Thank you very much for purchasing Transcend’s JetFlash™. This small device is designed to expedite the exchange of huge amounts of data between any desktop or laptop computers with a USB port. With higher storage capacity and a much faster data transfer rate than other typical portable storage media, JetFlash can easily replace floppy diskettes and hard disks.

  • Page 4: System Requirements

    System Requirements Desktop or notebook computer with USB port One of following operating systems: ® • Windows 98/98SE ® • Windows ® • Windows 2000 ® Windows • Mac™ OS 9.0 or later • Linux™ kernel 2.4 or later • Driver Installation for Windows 98/98SE 1.

  • Page 5: Driver Installation For Windows Me, 2000, And Xp

    Driver Installation for Windows Me, 2000, and XP No driver is required. These Windows operating systems have built-in drivers to support JetFlash. Simply plug JetFlash into an available USB port, and Windows will install the files needed to use your device. A new Removable Disk drive with a newly assigned drive letter appears in the My Computer window.

  • Page 6: How To Safely Unplug Jetflash

    Before removing JetFlash, please make sure the LED is steady and not flashing! If you remove JetFlash while the LED is flashing, unpredictable damage to the files and/or JetFlash may occur due to a write cache issue. How to Safely Unplug JetFlash To Remove JetFlash in Windows 98/98SE Unplug JetFlash from your system directly when data are not transferring.

  • Page 7: Write-Protect Function

    When the Write-Protect switch is set to Unlocked “ from JetFlash. When the Write-Protect switch is set to Locked “ JetFlash, but you can’t write data to JetFlash or format it. Please set the switch to Unlocked “ ” before attempting to format JetFlash. The Security Function is not supported by Mac or Linux Operating Systems.

  • Page 8: Security Function For Windows 98/98Se, Me, 2000, And Xp

    Only one data area can be seen at a time. You must “Log In” by entering the correct password to access data in the Security Area. You switch from Security Area to Public Area by using “Log Out.” Security Function for Windows 98/98SE, Me, 2000, and XP The default configuration of JetFlash is“Public Area Only”.
  • Page 9 the Driver for JetFlash. Click the U-Storage > U-Storage Driver Install. Follow the on-screen instructions to reinstall the driver for JetFlash. 4. Backup the data on your JetFlash. Make sure the Write-Protect switch is set to the position. 5. Double-click on 6.
  • Page 10 b. To partition your JetFlash to“Public Area + Security Area”, select Public Area + Security Area and click OK. The following window appears. Drag the horizontal slider to set the memory sizes to be apportioned to the Public Area and Security Area. ii.

  • Page 11: Access Data In Security Area

    Access Data in Security Area 1. Plug in JetFlash and the U-Storage window appears. To prevent the U-Storage window from coming up again, select Don’t pop up this window automatically next time. After selecting this box, you can display this window in the future only by double-clicking the 2.

  • Page 12: Log Out Of Security Area

    Area. 3. The Removable Disk window appears. The Security Area is ready for use. Log Out of Security Area 1. Make sure that no file is open and that no data are being transferred to or from your JetFlash. In Windows 2000, the File Manager must be closed. 2.

  • Page 13: Change Password

    have successfully completed Log Out, only data in the Public Area are accessible. Change Password 1. Double-click on the 2. The U-Storage window appears. Click on the Change Password button. 3. Key in the Current Password and enter the and the Confirm Password fields. (Maximum size for a password is 8 characters.) 4.

  • Page 14: If You Forget The Password

    6. Click OK to close this window. If You Forget the Password When you forget the password, all you can to use JetFlash again is run the U-Storage Tool to repartition JetFlash. Unfortunately, all data on JetFlash will be lost during this procedure. For systems that use Windows 98/98SE, Me, or XP, JetFlash can be configured to serve as an MS-DOS Boot Disk.
  • Page 15 2. Follow the on-screen instructions to complete U-Storage Tool installation. 3. Plug JetFlash into an available USB port of your computer. A in the Windows system tray. 4. Perform a backup of the data on your JetFlash. Make sure the Write-Protect switch is set to the position.

  • Page 16: Boot-Up Function For Windows Xp

    USB HDD option is only supported for the partition type of “Public Area Only” in Windows 98/98SE. To keep the Security Function in Windows, you can only select USB ZIP as the boot-up type. 7. The Warning message appears. Be sure you have made a backup of all the files on your JetFlash.
  • Page 17 2. Select Create an MS-DOS Startup Disk then click Start. 3. Click OK. 4. Click OK to complete the format.
  • Page 18 Skip steps 5-6 if the U-Storage Tool has already been installed. 5. Put the Driver CD into the CD-ROM drive (Auto-Run supported). Click the U-Storage Tool button. 6. Follow the on-screen instructions to complete U-Storage Tool installation. 7. Plug JetFlash into an available USB port of your computer, and a appears in the Windows system tray.
  • Page 19 10. Select USB ZIP and Click OK. 11. The Warning message appears. Be sure you have made a backup of all the files on your JetFlash. Click OK to continue or Cancel to exit. 12. The Completed alert box appears. JetFlash is now ready for use as an MS-DOS Boot Disk.

  • Page 20: Error Messages Of Boot-Up Function

    Error Messages of Boot-Up Function The initialization of the Boot-up Function or installation of the OS is probably incomplete. Please make sure that the path C:\WINDOWS\COMMAND\EBD exists in Windows 98/98SE, Me or XP. If yes, return to step 1 to re-initialize the Boot-up Function. If this fails, the Boot-up Function does not support your computer.
  • Page 21 2. Follow the on-screen instructions to complete U-Storage Tool installation. 3. Plug JetFlash into an available USB port of your computer. 4. Click the RecoverDisk to run the RecoverDisk program. RecoverDisk performs a low-level format on your JetFlash, erasing all data and returning JetFlash to the default configuration.
  • Page 22 6. Click YES if you want to recover your JetFlash. 7. When finished, the following status message appears. Click Close and unplug your JetFlash. Plug it in again to continue to use it.

  • Page 23: Uninstall The U-Storage Tool

    Uninstall the U-Storage Tool 1. Click the button on the Task Bar and select Programs > U-Storage > Uninstall U-Storage. 2. Follow the on-screen instructions to uninstall the U-Storage Tool.

  • Page 24: Specifications

    Specifications 75mm x 22mm x 10mm (Mini Size) Size: 88mm x 29mm x 12mm (Normal Size) 11 g (Mini Size) Weight: 22 g (Normal Size) Data Retention: Up to 10 years > 100,000 times Erase Cycles: Read 8.0 MB/sec (Max. for 128MB-4GB) Speed: Write 7.0 MB/sec (Max.

  • Page 25: Jetflash Limited Warranty

    Transcend. We consistently position ourselves to be significantly above the industry norm. It’s all part of our commitment to Customer Satisfaction. All Transcend Information, Inc. (Transcend) products are warranted and tested to be free from defects in material and workmanship and to conform to the published specifications. Should...
